ASME SA179 Carbon Steel Boiler Tube For Pressure Vessel

Brand Name:	Yuhong
Model Number:	Boiler Tube
MOQ:	1 PC
Price:	Negotiable
Packaging Details:	Ply-Wooden Case + Iron Frame
Payment Terms:	TT, LC

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ABS, BV, DNV, CCS, LR

Material Grade:

Standard:

ASTM A179 , ASME SA179

External Diameter:

>38.1

Ends:

PE , BE

Tube Material:

Nickel Alloy , Alloy , Stainless Steel , Duplex Stainless Steel , Carbon

Application:

Boiler

Supply Ability:

10000 Tons/Month

Highlight:

Pressure Vessel Boiler Tube

ASME SA179 Boiler Tube

Carbon Steel Boiler Tube

Product Description

ASME SA179 Carbon Steel Boiler Tube For Pressure Vessel

ASME SA179 is a specification under the ASME Boiler and Pressure Vessel Code that covers seamless cold-drawn low-carbon steel tubes designed for heat exchangers, condensers, and similar heat transfer applications. These tubes are widely used in industries such as power generation, petrochemical, and oil refining due to their excellent heat transfer properties and mechanical performance.

Chemical Composition:

Carbon: 0.06–0.15%
Manganese: 0.27–0.63%
Phosphorus: ≤ 0.035%
Sulfur: ≤ 0.035%
Silicon: 0.10–0.35%

Mechanical Properties:

Tensile Strength: 45,000–70,000 psi (310–480 MPa).
Yield Strength: 25,000 psi (172 MPa).
Elongation: Minimum of 30% in 8 inches (200 mm) of gauge length.
Hardness: Relatively low, contributing to its good formability and resilience in heat transfer applications.

Key Features:

Material: Low-carbon steel, providing good ductility and weldability.
Manufacturing Process: Cold-drawn seamless process, which ensures high dimensional accuracy and a smooth surface finish.
Heat Transfer Efficiency: Thin wall thickness and excellent thermal conductivity make them ideal for heat exchangers and condensers.
Compliance: Manufactured in accordance with ASME SA179/ASTM A179 standards, ensuring high-quality and reliable performance.

Dimensional Range

Outer Diameter (OD): 1/8 inch to 3 inches (3.2 mm to 76.2 mm).
Wall Thickness: 1.2 mm to 10 mm.
Length: As per customer requirements (typically up to 12 meters).

Applications:

Boiler systems.
Heat exchangers.
Condensers.
Superheaters.

Advantages

High heat transfer efficiency due to thin wall design.
Excellent surface finish, suitable for critical heat transfer applications.
High durability and corrosion resistance in high-pressure environments.
Easy fabrication and welding.

ASME SA179 Carbon Steel Boiler Tube For Pressure Vessel 0
