ASTM A335 P11 HFW Solid Fin Tube for Power Plants 16-219mm
  • name
  • name
  • name
  • name

ASTM A335 P11 HFW Solid Fin Tube for Power Plants 16-219mm

Brand Name: YUHONG
MOQ: 200-500KGS
Price: Negotiable
Packaging Details: Ply-wooden Cases with Steel Frames(both ends of pipes have plastic caps）
Payment Terms: L/C,T/T,AT SIGHT
Detail Information
Product Description
Ratings & Reviews
Detail Information
Place of Origin:
China
Certification:
ABS, BV, ISO, ASTM, SGS
Bare Tube Specification&Material:
ASTM A335 P11
Fin Type:
High Frequency Welded Fin Tube, Solid Fin Tuba
Application:
Inudustrial Furnaces, Power Plant , Refrigeration And Air Conditioning Systems
Bare Tube Diameter:
16-219 MM
Fin Pitch:
3-25 MM
Supply Ability:
According to Clients' requirements
Highlight:

ASTM A335 P11 HFW fin tube

,

solid fin tube for power plants

,

studded tube 16-219mm

Product Description
ASTM A335 P11 Seamless Alloy Steel HFW Solid Fin Tube For Power Plant
Product Specifications
Attribute Value
Bare Tube Specification & Material ASTM A335 P11
Fin Type High Frequency Welded Fin Tube, Solid Fin Tube
Application Industrial Furnaces, Power Plant, Refrigeration And Air Conditioning Systems
Bare Tube Diameter 16-219 MM
Fin Pitch 3-25 MM
Product Overview

ASTM A335 P11 HFW Solid Fin Tube is a high-temperature solution engineered for refinery and power applications. It features a seamless chromium-molybdenum alloy steel base tube (ASTM A335 P11, UNS K11597) with helically wound solid carbon steel fins bonded via high-frequency welding (HFW). This robust construction delivers exceptional oxidation and sulfidation resistance up to 565°C (1,050°F), making it ideal for heaters, superheaters, and coker units where thermal efficiency and corrosion resistance are critical.

Technical Specifications
Dimensional Specifications
Bare Tube Diameter Fin Height Fin Thickness Fin Pitch Tube Ends
16-219mm 5-30mm 0.8-3mm 3-25mm Plain Ends / Beveled Ends

No Fin Area (Both Ends): As Customer's Request and Drawing

Chemical Composition (%)
Element C Si Mo P Mn Cr S
Range 0.05-0.15 0.50-1.00 0.44-0.65 ≤ 0.025 0.30-0.60 1.00-1.50 ≤0.025
Mechanical Properties
Tensile Strength Yield Strength Elongation Hardness Max Service Temp.
≥415 MPa ≥205MPa ≥30% ≤ 163 HB 565°C (1050°F)
Key Applications & Competitive Advantages
  • Refinery Heaters: Convection sections in crude distillation units (NACE RP0472 compliant)
  • Delayed Cokers: Transfer line exchangers for 480°C+ vapors
  • Coal-Fired Boilers: Economizers handling >30g/Nm³ fly ash
  • Chemical Processing: Sulfuric acid regeneration heaters
  • Biomass Energy: High-temperature steam generators
Why Choose A335 P11 HFW Solid Fin Tube
Company Competitiveness

Yuhong Holding Group has more than 35 years experience for steel pipe and tube, fin tube, with main applications in Petrochemical, Oil refinery, Furnace, heating, boiler, heat exchanger, air cooler. The YUHONG brand products are exported to more than 85 countries including UK, ITALY, SPAIN, USA, MEXICO, COLOMBIA, BRAZIL, SAUDI ARABIA, OMAN, QATAR, U.A.E, KOREA, and has earned an excellent reputation in the market.

Product Advantages
  • 4X Sulfidation Life: Per API RP571 vs. carbon steel tubes
  • Zero Fin Detachment: HFW metallurgical bond >120 MPa (ISO 17639)
  • Cost Saving: 25% lower cost vs. P22 finned tubes
  • Fast Delivery: 80+ standard sizes (OD 25-152mm) in stock
