Embedded Fin Tube ASTM A179 Aluminium Strip Al1060 For Air Cooler

Embedded Fin Tube ASTM A179 Aluminium Strip Al1060 For Air Cooler

Product Overview:

The Embedded Fin Tube ASTM A179 with Aluminum Strip Al1060 is designed for air cooler applications, offering exceptional heat transfer efficiency and corrosion resistance. This fin tube combines carbon steel (ASTM A179) for the base tube with Al1060 aluminum for the fins, optimizing performance in industrial cooling systems, heat exchangers, and condensers.

Key Features:

1. Base Tube Material: ASTM A179 Carbon Steel

• ASTM A179 is a low-carbon steel tube known for its high thermal conductivity and mechanical properties. This material is ideal for use in heat exchangers and air coolers, where high strength and efficient heat transfer are required.
• The low-carbon content of the tube ensures that it is easy to weld and form, making it suitable for a wide range of industrial applications.

2. Fin Material: Aluminum Strip Al1060

• Al1060 aluminum offers excellent corrosion resistance, thermal conductivity, and lightweight properties. It is widely used in heat transfer applications because of its ability to dissipate heat quickly while being resistant to oxidation and rust.
• The aluminum fin strip is securely bonded to the base tube using an embedded fin design, which ensures that the fins remain attached even under high thermal cycling and mechanical stresses.

3. Fin Type: Embedded Fin

• The embedded fin design involves mechanically attaching aluminum fins to the tube, which increases the heat transfer area. This design ensures high heat exchange efficiency, particularly in air-cooling applications. The embedded fins prevent detachment and ensure long-term stability in harsh operating conditions.

4. Application: Air Cooler and Heat Exchanger

• The ASTM A179 tube with Al1060 aluminum fins is ideal for use in air coolers, heat exchangers, and condensers where heat needs to be dissipated efficiently.
• Common applications include industrial air cooling, HVAC systems, power plants, chemical processing, and refrigeration systems.

Chemical Composition

Base Tube: ASTM A179 Carbon Steel

Fin Material: Al1060 Aluminum

Mechanical Properties

Base Tube: ASTM A179 Carbon Steel

Fin Material: Al1060 Aluminum

Advantages:

1. Improved Heat Transfer Efficiency: The embedded fin design maximizes the surface area for heat exchange, ensuring high heat dissipation efficiency in air coolers and heat exchangers.
2. Corrosion Resistance: Al1060 aluminum provides excellent protection against oxidation and corrosion, ensuring a long-lasting and durable solution in harsh industrial environments.
3. Durability: The combination of ASTM A179 carbon steel for the base tube and Al1060 aluminum for the fins ensures a strong, reliable, and long-lasting tube suitable for high-pressure and high-temperature applications.
4. Lightweight: Aluminum fins are lightweight, reducing the overall weight of the heat exchanger system, which is particularly useful for large-scale industrial applications.
5. Cost-Effective: The combination of carbon steel base tubes and aluminum fins offers an affordable yet highly effective solution for air coolers and heat exchangers.

Applications:

• Air Coolers: For cooling air in industrial applications, particularly in power generation, chemical plants, and HVAC systems.
• Heat Exchangers: Ideal for industrial applications requiring efficient heat transfer, such as in chemical processing, marine cooling, and power plants.
• Condensers: Used in condensers for refrigeration systems, helping to cool and condense gases.
• HVAC Systems: Widely used in large-scale heating, ventilation, and air conditioning systems to ensure optimal cooling performance.
