Name: Air Cooler Tube ASTM A179 Carbon Steel Embedded Fin Tube With Al1060 Fin
Brand: YUHONG HOLDING GROUP CO., LTD
SKU: ASTM A179
Price: 10000.00 USD
Availability: InStock

Brand Name:	Yuhong
Model Number:	ASTM A179
MOQ:	100KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Payment Terms:	TT, LC

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ABS, BV, DNV, CCS, LR

Material:

ASTM A179

Fin Material:

Al1060, Al1100

Fin Type:

Embedded Type

Application:

Air Cooler, Refrigeration System

Fin Height:

15.875mm

Fin Thickness:

0.4MM

Highlight:

Al1060 Embedded Fin Tube

Air Cooler Embedded Fin Tube

ASTM A179 Embedded Fin Tube

Product Description

Air Cooler Tube ASTM A179 Carbon Steel Embedded Fin Tube with AL1060 Fin

Key Features:

Base Tube Material: ASTM A179 Carbon Steel, providing good strength, durability, and heat transfer capabilities. It is commonly used in air cooler applications due to its excellent mechanical properties and cost-effectiveness.
Fin Material: AL1060 Aluminum, a material known for its high thermal conductivity, light weight, and resistance to corrosion, making it ideal for efficient heat transfer in air cooler systems.
Fin Type: Embedded Fin, where the fins are integrally bonded to the tube surface, enhancing the overall heat exchange efficiency while minimizing any thermal resistance between the tube and the fins.
Application: Specifically designed for use in air cooler systems, the embedded fin tube offers high-performance cooling in industrial, HVAC, and power generation systems.

Technical Specifications:

Property	Base Tube (ASTM A179 Carbon Steel)	Fin Material (AL1060 Aluminum)
Outer Diameter (OD)	15.88 mm - 50.8 mm	Customizable based on design
Wall Thickness	1.0 mm - 3.0 mm	-
Fin Thickness	-	0.3 mm - 1.5 mm
Fin Height	-	10 mm - 30 mm
Fin Attachment	Embedded (integral bonding)	-

Chemical Composition:

Element	ASTM A179 Carbon Steel (Base Tube)	AL1060 Aluminum (Fin Material)
Carbon (C)	≤ 0.06%	≤ 0.03%
Manganese (Mn)	0.30% - 0.90%	≤ 0.03%
Phosphorus (P)	≤ 0.035%	-
Sulfur (S)	≤ 0.035%	-
Chromium (Cr)	≤ 0.30%	-
Nickel (Ni)	≤ 0.25%	-
Aluminum (Al)	-	≥ 99.0%

Mechanical Properties:

Property	ASTM A179 Carbon Steel (Base Tube)	AL1060 Aluminum (Fin Material)
Tensile Strength	335 - 485 MPa	70 - 110 MPa
Yield Strength	≥ 205 MPa	30 - 55 MPa
Elongation	≥ 30%	≥ 20%

Advantages:

Enhanced Heat Transfer: The embedded fin design increases the surface area for heat exchange, improving cooling efficiency in air cooler systems.
Corrosion Resistance: AL1060 aluminum provides superior resistance to corrosion, making it a long-lasting solution for air cooler applications, especially in humid or corrosive environments.
Cost-Effective: ASTM A179 carbon steel offers a more affordable solution compared to other high-alloy materials, without compromising on mechanical strength.
Durability and Strength: The combination of ASTM A179 carbon steel and AL1060 aluminum ensures the tube remains strong and reliable under high operational pressures and temperatures.

Applications:

Air Coolers: Widely used in air cooler systems, where high-efficiency heat transfer is required for cooling air or fluids.
HVAC Systems: In both residential and industrial HVAC units to maintain efficient cooling performance.
Industrial Cooling: Cooling applications in power plants, petrochemical plants, and manufacturing facilities.
Heat Exchangers: Used for cooling water, oil, or other fluids in heat exchanger systems across various industries.

Air Cooler Tube ASTM A179 Carbon Steel Embedded Fin Tube With Al1060 Fin 0
