Name: ASTM A213 T5 Fin Material Al1060 Embedded G Fin Tube For Refrigeration System
Brand: YUHONG HOLDING GROUP CO., LTD
SKU: ASTM A213 T5
Price: 10000.00 USD
Availability: InStock

ASTM A213 T5 Fin Material Al1060 Embedded G Fin Tube For Refrigeration System

Brand Name:	Yuhong
Model Number:	ASTM A213 T5
MOQ:	100KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Payment Terms:	TT, LC

Embedded G Fin Tube ASTM A213 T5 with AL1060 Fin Material for Refrigeration System

Key Features:

Base Tube Material: ASTM A213 T5 Alloy Steel, offering high-temperature strength and excellent resistance to oxidation, which makes it ideal for refrigeration systems operating in demanding conditions.
Fin Material: AL1060 Aluminum, known for its excellent thermal conductivity, corrosion resistance, and lightweight, making it a perfect choice for heat transfer applications in refrigeration.
Fin Type: Embedded G Fin, providing enhanced heat exchange efficiency by increasing the surface area and improving heat transfer performance in refrigeration systems.
Application: Designed specifically for refrigeration systems, optimizing the cooling efficiency of air coolers, evaporators, and condensers in HVAC systems.

Technical Specifications:

Property	Base Tube (ASTM A213 T5)	Fin Material (AL1060)
Outer Diameter (OD)	15.88 mm - 50.8 mm	Customizable based on design
Wall Thickness	1.5 mm - 4.0 mm	-
Fin Thickness	-	0.3 mm - 0.7 mm
Fin Height	-	10 mm - 30 mm
Fin Attachment	Mechanically embedded (G-type)

Chemical Composition:

Element	ASTM A213 T5 (Base Tube)	AL1060 (Fin Material)
Carbon (C)	0.05% - 0.15%	≤ 0.03%
Manganese (Mn)	0.30% - 0.60%	≤ 0.03%
Phosphorus (P)	≤ 0.025%	-
Sulfur (S)	≤ 0.025%	-
Chromium (Cr)	4.00% - 6.00%	-
Nickel (Ni)	1.00% - 2.00%	-
Aluminum (Al)	-	≥ 99.6%

Mechanical Properties:

Property	ASTM A213 T5 (Base Tube)	AL1060 (Fin Material)
Tensile Strength	≥ 415 MPa	60 - 100 MPa
Yield Strength	≥ 205 MPa	30 - 50 MPa
Elongation	≥ 30%	≥ 25%

Advantages:

Enhanced Heat Transfer: The embedded G-fin design increases surface area, optimizing heat dissipation and improving the refrigeration system's efficiency.
Corrosion Resistance: AL1060 fins are highly resistant to oxidation and corrosion, ensuring long-lasting performance in refrigeration applications.
High-Temperature Durability: ASTM A213 T5's resistance to high temperatures makes it ideal for refrigeration systems exposed to thermal cycling.
Lightweight and Cost-Effective: AL1060 aluminum fins are lightweight and cost-effective, reducing overall system weight while maintaining high thermal conductivity.

Applications:

Refrigeration Systems: Used in air coolers, evaporators, and condensers to enhance heat exchange efficiency.
HVAC Systems: For cooling in residential, commercial, and industrial HVAC systems.
Chillers and Coolers: Used in industrial refrigeration systems to cool fluids and gases efficiently.
Food Processing: Cooling systems for perishable goods storage and transport.

ASTM A213 T5 Fin Material Al1060 Embedded G Fin Tube For Refrigeration System 0

Property

Base Tube (ASTM A213 T5)

Fin Material (AL1060)

Outer Diameter (OD)

15.88 mm - 50.8 mm

Customizable based on design

Wall Thickness

1.5 mm - 4.0 mm

Fin Thickness

0.3 mm - 0.7 mm

Fin Height

10 mm - 30 mm

Fin Attachment

Mechanically embedded (G-type)

Element

ASTM A213 T5 (Base Tube)

AL1060 (Fin Material)

Carbon (C)

0.05% - 0.15%

≤ 0.03%

Manganese (Mn)

0.30% - 0.60%

≤ 0.03%

Phosphorus (P)

≤ 0.025%

Sulfur (S)

≤ 0.025%

Chromium (Cr)

4.00% - 6.00%

Nickel (Ni)

1.00% - 2.00%

Aluminum (Al)

≥ 99.6%

Property

ASTM A213 T5 (Base Tube)

AL1060 (Fin Material)

Tensile Strength

≥ 415 MPa

60 - 100 MPa

Yield Strength

≥ 205 MPa

30 - 50 MPa

Elongation

≥ 30%

≥ 25%
