ASME SA213 TP347H Seamless Stainless Steel Boiler Tube For Petrochemical Industry

Brand Name:	Yuhong
Model Number:	Boiler Tube
MOQ:	1 PC
Price:	Negotiable
Packaging Details:	Ply-Wooden Case + Iron Frame
Payment Terms:	TT, LC

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ABS, BV, DNV, CCS, LR

Material Grade:

TP347H

Standard:

ASTM A213 , ASME SA213

External Diameter:

>38.1

Ends:

PE , BE

Tube Material:

Nickel Alloy , Alloy , Stainless Steel , Duplex Stainless Steel , Carbon

Application:

Boiler

Supply Ability:

10000 Tons/Month

Highlight:

ASME SA213 Stainless Steel Boiler Tube

Seamless Stainless Steel Boiler Tube

Petrochemical Industry Seamless Stainless Steel Tubing

Product Description

ASME SA213 TP347H Seamless Stainless Steel Boiler Tube For Petrochemical Industry

TP347H is a niobium-containing Cr-Ni austenitic stainless steel with good high-temperature strength and organizational stability. It has excellent oxidation resistance and soothing reaction properties. In addition, the material has good bending and welding properties, making it suitable for a wide range of applications in a variety of complex working conditions.

Chemical Composition:

Grade	C	Cr	Ni	Mn	Si	P	S	Nb+Ta
TP347H	0.04-0.10%	17.0-19.0%	9.0-13.0%	2.0% max	0.75% max	0.045% max	0.030% max	8xC-1.00% max

Mechanical Properties:

Grade

Tensile Strength

Yield Strength

Elongation

Hardness

TP347H

Minimum

515 MPa (75 ksi)

Minimum

205 MPa (30 ksi)

20% minimum

in 50 mm

≤ 220 HB

(Brinell Hardness)

Key Features:

High-Temperature Strength: Ensures reliable performance in high-temperature applications.
Oxidation Resistance: Provides excellent resistance to oxidation in demanding environments.
Creep Resistance: High resistance to creep, ensuring long-term reliability under continuous high-temperature exposure.
Durability: High tensile strength and toughness provide long service life in demanding conditions.
Weldability: Good weldability allows for easy fabrication and repair of boiler tubes.
Versatility: Suitable for a wide range of high-temperature and high-pressure applications across various industries.

Applications:

1. Petrochemical Industry

Refinery Equipment: Critical for refinery equipment that processes high-temperature and high-pressure steam.
Cracking Units: Suitable for catalytic cracking units where high temperatures and corrosion resistance are essential.
Heat Exchangers: Employed in high-temperature heat exchangers in petrochemical plants.

2. Marine Applications

Marine Boilers: Used in marine boilers for steam generation on ships and submarines.
Heat Exchangers: Suitable for marine heat exchangers exposed to high-pressure steam.
Engine Systems: Used in high-pressure steam systems in marine engine rooms.

3. Oil and Gas Industry

Offshore Platforms: Suitable for components in offshore platforms exposed to high temperatures and corrosive environments.
Downhole Tubing: Used in downhole tubing for oil and gas extraction where high-temperature strength is required.
Refinery Equipment: Ideal for refinery equipment processing sour gas and other corrosive substances at high temperatures.

ASME SA213 TP347H Seamless Stainless Steel Boiler Tube For Petrochemical Industry 0
