SA213 TP304L is a low-carbon austenitic stainless steel (18% Cr, 8% Ni, low C) used in U-bend boiler tubes for high-corrosion resistance and flexibility in heat exchangers.

Primary Applications
1. Heat Exchangers & Condensers

Shell & tube heat exchangers (U-bends allow thermal expansion).
Surface condensers in power plants (resists steam/condensate corrosion).

2. Boilers & Superheaters

Recovery boilers (handles flue gas condensates).
Low-pressure steam boilers (where chloride stress corrosion is a concern).

3. Petrochemical & Refining

Reboilers, feedwater heaters (resists acidic/alkaline conditions).
Refinery heat recovery systems (exhaust gas applications).

4. Food & Pharmaceutical Processing

Sanitary heat exchangers (non-reactive, easy to clean).

5. Marine & Desalination

Desalination plant tubing (resists saltwater pitting/crevice corrosion).

Why Use SA213 TP304L U-Bend Tubes?

✔ Excellent corrosion resistance (vs. carbon steel in acidic/chloride environments).
✔ Low carbon content (0.03% max) – prevents sensitization & intergranular corrosion.
✔ Good weldability – no post-weld heat treatment required.
✔ High ductility – U-bends withstand thermal expansion stresses.
✔ Oxidation resistance up to ~800°C (1472°F).

Comparison with Other Grades

Grade	Key Features	Best For
TP304L	Low carbon, general corrosion resistance	Most heat exchangers, food/pharma
TP316L	Added Mo (2-3%), better chloride resistance	Marine, desalination, harsh chemicals
TP321	Ti-stabilized, resists sensitization	High-temp exhausts, aircraft
TP347	Nb-stabilized, superior creep resistance	Superheaters, high-pressure steam

Common FAQs
1. Can TP304L handle high-pressure steam?

Yes, but for >500°C (932°F), TP321/TP347 is preferred due to better creep strength.

2. Why U-bend instead of straight tubes?

Absorbs thermal expansion (reduces stress on tube sheets).
Compact design (saves space in heat exchangers).

3. How to prevent stress corrosion cracking (SCC)?

Avoid chloride exposure >60°C (140°F).
Use TP316L if chlorides are present.

4. What’s the max operating temperature?

Continuous: ~800°C (1472°F) (oxidizing environments).
For pressure service: ~425°C (797°F) per ASME limits.

5. How to inspect U-bend tubes?

Dye penetrant (PT) for surface cracks.
Radiography (RT) for internal defects.
Need Custom Specifications
Bend radius: Standard (1.5D–3D) or custom.
Finishing: Pickling/passivation for enhanced corrosion resistance.
Certification: EN 10204 3.1 / MTC with PMI test reports.

SA213 TP304L Stainless Steel U Bend Boiler Tube For Hot Water Boilers and Condensers 0

Tags:

Products Details

Home > Products >

Boiler Tube

SA213 TP304L Stainless Steel U Bend Boiler Tube For Hot Water Boilers and Condensers

All Category

SA213 TP304L Stainless Steel U Bend Boiler Tube For Hot Water Boilers and Condensers

Brand Name:	Yuhong
MOQ:	1PC
Price:	Negotiable
Packaging Details:	WOODEN CASE WITH PLASTIC CAP
Payment Terms:	TT, LC

Detail Information

Product Description

Detail Information

Place of Origin:

China

Brand Name:

Yuhong

Certification:

ABS, BV, DNV, CCS, LR

Tube Material:

A179, A106, A210

Length:

Max 34M/PC

O.D.:

6-50.8mm

W.T.:

0.5-15mm

Testing:

UT, ET, HT, PMI

Product Name:

Stinless Steel U Bend Boiler Tube

Minimum Order Quantity:

1PC

Price:

Negotiable

Packaging Details:

WOODEN CASE WITH PLASTIC CAP

Delivery Time:

According to the quantity

Payment Terms:

TT, LC

Supply Ability:

10000 tons/month

Highlight:

SA213 Stainless Steel Boiler Tube

TP304L Stainless Steel Boiler Tube

Stainless Steel U Bend Boiler Tube

Product Description

ASME SA213 TP304L U-Bend Boiler Tube – Applications & Key Features

SA213 TP304L is a low-carbon austenitic stainless steel (18% Cr, 8% Ni, low C) used in U-bend boiler tubes for high-corrosion resistance and flexibility in heat exchangers.

Primary Applications
1. Heat Exchangers & Condensers

Shell & tube heat exchangers (U-bends allow thermal expansion).
Surface condensers in power plants (resists steam/condensate corrosion).

2. Boilers & Superheaters

Recovery boilers (handles flue gas condensates).
Low-pressure steam boilers (where chloride stress corrosion is a concern).

3. Petrochemical & Refining

Reboilers, feedwater heaters (resists acidic/alkaline conditions).
Refinery heat recovery systems (exhaust gas applications).

4. Food & Pharmaceutical Processing

Sanitary heat exchangers (non-reactive, easy to clean).

5. Marine & Desalination

Desalination plant tubing (resists saltwater pitting/crevice corrosion).

Why Use SA213 TP304L U-Bend Tubes?

Comparison with Other Grades

Grade	Key Features	Best For
TP304L	Low carbon, general corrosion resistance	Most heat exchangers, food/pharma
TP316L	Added Mo (2-3%), better chloride resistance	Marine, desalination, harsh chemicals
TP321	Ti-stabilized, resists sensitization	High-temp exhausts, aircraft
TP347	Nb-stabilized, superior creep resistance	Superheaters, high-pressure steam

Common FAQs
1. Can TP304L handle high-pressure steam?

Yes, but for >500°C (932°F), TP321/TP347 is preferred due to better creep strength.

2. Why U-bend instead of straight tubes?

Absorbs thermal expansion (reduces stress on tube sheets).
Compact design (saves space in heat exchangers).

3. How to prevent stress corrosion cracking (SCC)?

Avoid chloride exposure >60°C (140°F).
Use TP316L if chlorides are present.

4. What’s the max operating temperature?

Continuous: ~800°C (1472°F) (oxidizing environments).
For pressure service: ~425°C (797°F) per ASME limits.

5. How to inspect U-bend tubes?

Dye penetrant (PT) for surface cracks.
Radiography (RT) for internal defects.
Need Custom Specifications
Bend radius: Standard (1.5D–3D) or custom.
Finishing: Pickling/passivation for enhanced corrosion resistance.
Certification: EN 10204 3.1 / MTC with PMI test reports.
