Stainless Steel Boiler Tube,ASME SA213 TP347H, Power Plant Boiler Application

Brand Name:	Yuhong
Model Number:	ASTM A213 , ASME SA213 , ASTM A376, ASME SA376, TP347, TP347H
MOQ:	1PC
Price:	Negotiable
Packaging Details:	Bundle + Cap , Ply wooden case
Payment Terms:	TT, LC

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ABS, BV, DNV, CCS, LR

Material Grade:

TP347, TP347H, 1.4550, 1.4551

Material Standard:

ASTM A213, ASME SA213, JIS G3459, EN10216-5, GOST 9941-81, ASTM A376 , ASME SA376

ET, UT, HT, PT, PMI

Size OD:

31.75 ~ 165.2mm

Size Thickness:

2~20mm

Size Length:

Max.: 34m/pc

Supply Ability:

10000 tons/month

Highlight:

TP347H Stainless Steel Boiler Tube

Stainless Steel Boiler Tube ASTM

Power Plant boiler superheater tube

Product Description

Stainless Steel Boiler Tube,ASME SA213 TP347H, Power Plant boiler application

Yuhong group ASME SA213 TP347H grade main for power plant application, this grade need arrange stabilization Heat Treatment, during the last heat teament , usually Yuhong Group control the Furnace temperature around 950℃, and keep time around 2 ~4 hours .

Yuhong Group ASME SA213 TP347H Stainless Steel Boiler Tube datasheet :

Out Side Diameter: 31.75mm , 38.1mm , 44.45mm , 50.8mm , 57.15mm , 63.5mm, 76.2mm, .... 165.2mm ;
Wall thickness: 2mm to 20mm
Length: Max.: 34m/pc

All tubes of ASME SA213 match Grain Size <7. (ASTM E112 );

All tubes with 100% Eddy Current Test (ASTM E426);

All tubes with 100% Hydrostatic Test ( ASTM A1016 - 7Mpa/5s );

Tests of TP347,TP347H Stainless Steel Boiler Tube
1.Chemical Analysis
2.Mechanical Properties
2.1Tensile Requirement
2.2Hardness Requirement
2.3Flattening Test
2.4Flaring Test
3.Hydrostatic Test or Nondestructive Electric Test

Chemical Composition of ASME SA213 TP347 , TP347H :

Grade		C	Mn	Si	P	S	Cr	Mo	Ni	Niobium	Other
TP347	min.	-	2.0	1.0	0.045	0.03	17	-	9	10*C ~1.10	/
	max	0.08					19		13		/
TP347H	min.	0.04	2.0	1.0	0.045	0.03	17	-	9	8*C ~1.10	/
	max	0.1					19		13		/

Mechanical Properties of ASME SA213 TP347, TP347H:

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness
				Rockwell B (HRB) max	Brinell (HBW) max
TP347	515	205	35	90	192
TP347H	515	205	35	90	192
TP347H also has a requirement for a grain size of ASTM No 7 or coarser.

ASME SA213 TP347H Stainless Steel Boiler Tube application:

1. Food preparation equipment;
2. Laboratory benches & equipment;
3. Coastal architectural panelling, railings & trim;
4. Power Plant Boiler;
5. Chemical containers, including for transport；
6. Heat Exchanger；
7. Oil and Gas；
8. Petrochemical；
9. Super Heater parts；
10. Furnace.
