Serrated Fin Tube ASME SA335 11 Alloy Steel Seamless Pipe For Heater
Product Description
ASME SA335 P22 alloy steel seamless pipe serrated fin tube is manufactured by attaching serrated fin strips onto the base tube surface through high-frequency welding (HFW). The serrated fins are slit along their length to create small interruptions, which significantly improve turbulence and heat transfer efficiency. This makes the product highly suitable for Heat Recovery Steam Generator (HRSG) systems, boilers, and furnaces, where high-temperature and high-pressure performance is essential.
Chemical Composition – ASME SA335 P11
| Element | C | Mn | Si | Cr | Mo | P | S |
|---|---|---|---|---|---|---|---|
| % | 0.05–0.15 | 0.30–0.60 | 0.50–1.00 | 1.00–1.50 | 0.44–0.65 | ≤0.025 | ≤0.025 |
Mechanical Properties – ASME SA335 P11
| Property (Row) | Requirement |
|---|---|
| Tensile Strength (MPa) | ≥ 415 |
| Yield Strength (MPa) | ≥ 205 |
| Elongation (%) | ≥ 30 |
Enhanced heat transfer: serrated fins break boundary layers, improving heat transfer efficiency
High-temperature resistance: P11 alloy steel performs well in elevated temperature environments
Strong metallurgical bonding: HFW ensures excellent fin-to-tube attachment strength
Durability: withstands oxidation, creep, and thermal cycling in HRSG systems
Enhanced heat transfer due to serrated fin geometry
High-temperature resistance suitable for heater and furnace service
Strong welded joint provides excellent durability
Improved gas-side turbulence and efficiency
Applications
Process Heaters
Petrochemical Furnace Coils
Waste Heat Recovery Units
Refinery Heating Systems
