ASME SA179 Carbon Steel Wound Fin Tube KL Type With Aluminium 1060 Strip

Brand Name:	Yuhong
Model Number:	ASTM A179
MOQ:	100KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with Plastic Cap
Payment Terms:	L/C, T/T

Detail Information

Product Description

Ratings & Reviews

Detail Information

Place of Origin:

China

Certification:

DNV, BV, PED, LR, ABS, TS, CCS

Fins:

AL1060

Base Tube Material:

Fin Material:

AL1060

Fin Thk:

0.4mm

Fin Materials:

Aluminium, Copper

HT/ECT

Application:

Air Cooler

Supply Ability:

1000 ton/month

Highlight:

ASME SA179 carbon steel fin tube

KL type wound fin tube

aluminum 1060 strip fin tube

Product Description

ASME SA179 Carbon Steel Wound Fin Tube KL Type With Aluminium 1060 Strip

Product Description

The ASME SA179 carbon steel wound fin tube (KL type) is manufactured by tightly winding an Aluminium 1060 strip around the base carbon steel tube. The foot of each fin strip is knurled (K) into the tube surface to improve bonding strength, and then the strip is tension wound (L) along the tube length to ensure close contact and excellent thermal conductivity. This construction provides a reliable combination of mechanical strength and heat transfer efficiency, ideal for air coolers and other heat exchanger systems.

Chemical Composition (ASME SA179 Base Tube)

Element	C	Mn	P (max)	S (max)
Content (%)	≤ 0.06	0.27–0.63	0.035	0.035

Mechanical Properties (ASME SA179 Base Tube)

Property	Requirement
Tensile Strength	≥ 325 MPa
Yield Strength	≥ 180 MPa
Elongation	≥ 35%
Hardness	≤ 72 HRB

Chemical Composition (Aluminium 1060 Fin Strip)

Element	Al	Si	Fe	Cu	Mn	Zn	Others (each)	Others (total)
Content (%)	≥ 99.6	≤ 0.25	≤ 0.35	≤ 0.05	≤ 0.03	≤ 0.05	≤ 0.03	≤ 0.10

Features of KL Type Wound Fin Tube

Knurled + wound structure for strong mechanical bonding between fin and tube
Excellent heat transfer due to full contact between fin strip and tube surface
Lightweight corrosion-resistant aluminium fins improve thermal efficiency and reduce overall weight
High mechanical strength to withstand vibration and thermal cycling in air cooler

Applications

Air cooler units in power plants and refineries
Heat exchangers in petrochemical and chemical industries
Gas compressors and condensers
Process cooling systems

Advantages

ASME SA179 Carbon Steel Wound Fin Tube KL Type With Aluminium 1060 Strip 0

Cost-effective solution for large air-cooling systems
Efficient thermal conductivity with low thermal resistance
High surface area increases heat dissipation efficiency
Long service life under continuous operation
