ASTM A789 S32750 Duplex Stainless Steel Seamless Tube

Brand Name:	Yuhong
Model Number:	ASTM A789 S32750
MOQ:	100kgs
Price:	Negotiable
Packaging Details:	Ply-woonden case
Payment Terms:	T/T,L/C

Detail Information

Product Description

Ratings & Reviews

Detail Information

Place of Origin:

China

Certification:

ABS, BV, CCS, LR

Shape:

Round

Corrosion Resistance:

Size:

Customized

Cost-Effectiveness:

Length:

Customized

Materials:

S32750

Testing:

UT, ET, HT, PMI

Ends:

Material:

Duplex Stainless Steel

Standards:

ASTM A789 , ASME SA789

Supply Ability:

1000 ton per tons

Highlight:

ASTM A789 S32750 seamless tube

Duplex stainless steel heat exchanger tube

S32750 stainless steel seamless pipe

Product Description

ASTM A789 S32750 Duplex Stainless Steel Seamless Tube

Product Specifications

Attribute	Value
Shape	Round
Corrosion Resistance	High
Size	Customized
Cost-Effectiveness	High
Length	Customized
Materials	S32750
Testing	UT, ET, HT, PMI
Ends	PE
Material	Duplex Stainless Steel
Standards	ASTM A789, ASME SA789

Product Overview

The ASTM A789 S32750 Duplex Steel Seamless Tube is manufactured from S32750 duplex stainless steel, which combines both austenitic and ferritic properties to offer superior corrosion resistance, strength, and toughness. This tube is designed for heat exchanger systems, particularly in aggressive environments such as seawater, chemical processing, and petrochemical industries.

Chemical Composition - ASTM A789 S32750 Duplex Steel

Element	Content (%)
C	≤ 0.03
Mn	1.00 - 2.00
Si	0.80 - 1.20
P	≤ 0.035
S	≤ 0.015
Cr	24.0 - 26.0
Ni	6.0 - 8.0
Mo	3.0 - 5.0
N	0.24 - 0.32
Fe	Balance

Mechanical Properties - S32750 Duplex Steel

Property	Value
Tensile Strength	≥ 550 MPa
Yield Strength	≥ 450 MPa
Elongation	≥ 25%
Hardness	≤ 250 HB
Impact Toughness	Excellent, even at low temp.
Maximum Operating Temp	300°C (572°F)

Key Advantages

Superior Corrosion Resistance - Excellent resistance to pitting, crevice corrosion, and stress corrosion cracking (SCC), especially in chloride-rich environments.
High Strength and Durability - Offers higher tensile strength than traditional austenitic stainless steels, with better performance in high-pressure systems.
Cost-Effective for Aggressive Environments - The combination of austenitic and ferritic phases makes this duplex steel a more affordable solution for harsh applications.
Outstanding Heat Transfer Efficiency - The tube design ensures optimal fluid flow and heat transfer, essential for efficient operation in heat exchanger applications.
Long Service Life - Superior resistance to corrosion fatigue and mechanical wear ensures long-term performance in extreme conditions.

Typical Applications

This tube is used extensively in the following heat exchanger applications:

Seawater Heat Exchangers - Ideal for marine environments or applications exposed to seawater.
Petrochemical Industry - Used in cooling systems and heat exchangers where aggressive chemical processes are involved.
Power Plants - Effective for HRSG systems and economizers in both fossil fuel and nuclear plants.
Chemical Processing Units - Effective in high-pressure chemical reactors and heat exchanger systems dealing with corrosive materials.
