ASTM A213 TP347H Serrated Finned Tube For Refrigeration And Air Conditioning Systems

Brand Name:	YUHONG
MOQ:	200-500KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Cases with Steel Frames(both ends of pipes have plastic caps）
Payment Terms:	L/C,T/T,AT SIGHT

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ABS, BV, ISO, ASTM, SGS

Bare Tube Specification&Material:

ASTM A213 TP347H

Product Name:

Serrated Finned Tube / Serrated Spiral High Frequency Welding Finned Tube

Application:

Power Plants, Heat Exchangers, Air Preheaters,HVAC Systems

Highlight:

ASTM A213 Finned Tube, Serrated Spiral Finned Tube, Heat Exchanger Finned Tube

Supply Ability:

According to Clients' requirements

Highlight:

ASTM A213 TP347H Finned Tube

Refrigeration Serrated Finned Tube

Air Conditioning Serrated Finned Tube

Product Description

1. What is ASTM A213 TP347H Serrated Finned Tube?

ASTM A213 TP347H Serrated Finned Tube is an ultra-high-temperature heat transfer solution engineered for critical creep-resistance applications. It features a seamless niobium-stabilized austenitic stainless steel base tube (ASME SA213 TP347H) with helically wound serrated fins resistance-welded to the surface. This design delivers exceptional oxidation resistance up to 900°C (1,652°F) and prevents carbide precipitation in continuous service, making it the premier choice for superheaters, reformers, and waste heat boilers in aggressive environments.

1. ASTM A213 TP347H Stainless Steel Seamless Fin Tube

Dimensional Specifications

Base Tube O.D:15.88–325 mm
Fin Height:15.88–325 mm	Fin Thickness: 0.8–3.0 mm	Fin Pitch: As Customer’s Request	Tube Ends: Plain Ends / Beveled Ends
No Fin Area (Both Ends): As Customer’s Request and Drawing

Chemical Composition (%)

Element	C	Si	Mn	P	S	Cr	Ni	Nb	Others
Range	0.04~0.10	≤0.75	≤2.00	≤0.040	≤0.030	17.0~19.0	9.0~13.0	≥10×C, ≤1.00	Balance (Fe)

Note: Nb content must satisfy ≥10×C and ≤1.00%.

Mechanical Properties

Tensile Strength: Rm (MPa)	Yield Strength: Rp 0.2 (MPa)	Elongation: A (%)
≥515	≥205	≥35

3. Key Applications & Competitive Advantages

· Power Plant Boilers: Superheaters/reheaters in 600°C+ USC coal units.

· Petrochemical: Ethylene cracker transfer line exchangers.

· Waste-to-Energy: Superheaters for corrosive waste incinerators.

· Chemical Processing: Hydroprocessing furnace convection banks.

· Steel Mills: Recuperators for coke oven gas.

4. Why Choose ASTM A370 TP347H

A:Company Competitiveness:

Yuhong Holding Group has more than 35 years experience for steel pipe and tube , fin tube , main application for Petrochemical , Oil refinary, Furnace, heating, boiler, heat exchanger, air cooler,.., till now YUHONG brand products already exported more than 85 countries, which like UK, ITALY, SPAIN , USA, MEXICO , COLOMBIA , BRAZIL, SAUDI ARANBIA , OMAN, QATAR, U.A.E, KOREA, ...., YUHONG brand already won good reputation in the market.

B:Product Competitiveness:
·  Zero Sensitization: Nb stabilization eliminates post-weld heat treatment.
·  Ash Erosion Defense: Serrations reduce fouling by 45% (EPRI Field Data).
·  Life Extension: 3x longer service than TP321H in 700°C flue gas.
·  Custom Engineered: No-fin zones, fin pitch, and bevels per client drawings.

ASTM A213 TP347H Serrated Finned Tube For Refrigeration And Air Conditioning Systems 0
