B407 N08810 Incoloy 800H Nickel Alloy Steel Seamless Tube For Superheaters And Furnance

Brand Name:	Yuhong
MOQ:	1PC
Price:	Negotiable
Packaging Details:	WOODEN CASE WITH PLASTIC CAP
Payment Terms:	TT, LC

Detail Information

Product Description

Detail Information

Place of Origin:

China

Brand Name:

Yuhong

Certification:

ABS, BV, DNV, CCS, LR

Tube Material:

N04400, N06600, N08800, N08810, N08811, N08825

Length:

Max 34M/PC

O.D.:

6-203mm

W.T.:

0.5-25mm

Testing:

UT, ET, HT, PMI

Minimum Order Quantity:

1PC

Price:

Negotiable

Packaging Details:

WOODEN CASE WITH PLASTIC CAP

Delivery Time:

According to the quantity

Payment Terms:

TT, LC

Supply Ability:

10000 tons/month

Highlight:

Furnance Nickel Alloy Seamless Tube

Superheaters Seamless Tube

Furnance Seamless Tube

Product Description

ASTM A407 N08810 Heat Exchanger Tube Chemical Composition

UNS Designation	Ni	Cu	Iron	Mn	C	Cr	Ti	Al
N08810	0.30–0.35	0.75	39.5	1.5	0.05–0.10	19.0-23.0	0.15-0.60	0.15-0.60

ASTM B407 N08810 Heat Exchanger Tube Application

Tubes are used in extreme environments:

Petrochemical: Ethylene furnace coils, reformer tubes, pyrolysis units.
Power Generation: Superheater tubes, heat exchangers, boiler components.
Nuclear: Steam generator tubing, heat exchangers (resists chloride stress corrosion).
Industrial Furnaces: Radiant tubes, muffles, conveyor systems.
Chemical Processing: Acid production, catalyst support grids.

Application	Primary Challenge	800H’s Advantage
Ethylene cracking	Carburization + creep	Controlled carbon + Ni/Cr matrix stability
Nuclear steam gens	SCC in chlorides	>30% Ni content prevents cracking
Reformer tubes	Hydrogen embrittlement	Stable austenitic structure
Radiant furnace tubes	Cyclic oxidation/carburizing	Al/Ti oxide layer formation

ASTM B407 N08810 Heat Exchanger Tube Strength & Mechanical Properties

Room Temperature:

Tensile Strength: ≥500 MPa (72.5 ksi)

Yield Strength (0.2% offset): ≥170 MPa (25 ksi)

Elongation: ≥30%

Elevated Temperature (650°C / 1200°F):

Tensile Strength: ~380 MPa (55 ksi)

Creep Rupture Strength: Excellent (e.g., 10,000 hrs at 815°C: ~20 MPa)

Key Strengths: Retains structural integrity under thermal cycling/stress; superior to standard stainless steels (e.g., 304/316) above 600°C.
High-Temperature Performance: Outperforms stainless steels in creep strength above 600°C.
Corrosion Resistance: Resists oxidation, carburization, and reducing sulfur atmospheres.
Fabricability: Weldable (using ENiCrFe-3 filler) and formable with standard methods.
Cost-Effective: More economical than high-nickel alloys (e.g., Inconel) for moderate temperatures.

ASTM B407 N08810 Heat Exchanger Tube FAQ

1. What distinguishes Incoloy 800H from standard Incoloy 800?

800H has a higher carbon content (0.05–0.10% vs. 0.03% max in 800) for superior creep resistance at >600°C.

It undergoes solution annealing at ≥1100°C to achieve an ASTM No. 5 or coarser grain size, optimizing high-temperature strength.

2. What temperatures can Incoloy 800H tubes handle?

Continuous Service: Up to 815°C (1500°F).

Short-Term Exposure: Up to 950°C (1740°F).

Critical Note: For >900°C, Incoloy 800HT (Ti/Al-controlled) is preferred for enhanced stability.

3. Is welding 800H tubes difficult?

Weldable via:

TIG/GTAW with ERNiCr-3 (FM 82) filler.

SMAW with ENiCrFe-3 electrodes.

Post-Weld Requirement: Solution annealing (1100–1175°C) is essential to restore corrosion/creep resistance.
