ASTM A268 TP430 Stainless Steel Heat Exchanger Tube For Condensers

Brand Name:	Yuhong
Model Number:	Seamless tube
MOQ:	1 PC
Price:	Negotiable
Packaging Details:	Bundle + Cap , Ply wooden case
Payment Terms:	TT, LC

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ABS, BV, DNV, CCS, LR

Material:

TP430

Standard:

ASTM A268 , ASME SA268

ET, UT, HT, PT, PMI

Size OD:

6~203mm

Size Thickness:

0.5~25mm

Size Length:

Max.: 25m/pc

Supply Ability:

10000 Tons/Month

Highlight:

TP430 Stainless Steel Heat Exchanger Tube

Condensers Stainless Steel Heat Exchanger Tube

Product Description

ASTM A268 TP430 Stainless Steel Heat Exchanger Tube For Condensers

ASTM A268 TP430 Stainless Steel Tube is a ferritic stainless steel tube that offers good corrosion resistance, oxidation resistance, and thermal stability at elevated temperatures. It is commonly used in heat exchangers, automotive exhaust systems, boilers, and furnace components. TP430 provides excellent performance in moderately corrosive environments and under high-temperature conditions, making it an ideal choice for industries such as chemical processing, petrochemical, power generation, and food processing. With its good weldability, thermal cycling resistance, and mechanical strength, TP430 is a reliable material for a variety of applications where heat transfer, durability, and performance under stress are key.

Chemical Composition(%):

- Chromium (Cr): 16.0% - 18.0%

- Nickel (Ni): 0.75% max

- Manganese (Mn): 1.0% max

- Silicon (Si): 1.0% max

- Carbon (C): 0.12% max

- Phosphorus (P): 0.04% max

- Sulfur (S): 0.03% max

- Iron (Fe): Balance

Mechanical Properties:

- Tensile Strength: ~ 480 MPa (70,000 psi) (typical)

- Yield Strength: ~ 205 MPa (30,000 psi) (typical)

- Elongation: ~ 25% (in 50 mm gauge length)

- Hardness: ~ HRB 90 (typical)

Physical Properties:

- Density: ~ 7.70 g/cm³

- Melting Point: ~ 1400°C (2552°F)

- Thermal Conductivity: ~ 25.4 W/m·K (at 100°C)

- Specific Heat: ~ 460 J/kg·K

- Modulus of Elasticity: ~ 200 GPa

- Thermal Expansion: ~ 11.5 × 10^-6 /°C (at 20°C to 100°C)

Applications:

Heat Exchangers
Automotive Exhaust Systems
Boilers and Furnace Components
Food and Dairy Processing
Petrochemical and Chemical Industry
Power Generation
Marine and Offshore
Industrial Heating Systems

ASTM A268 TP430 Stainless Steel Heat Exchanger Tube For Condensers 0
