ASTM A179 Wound Fin Tube L Type With Material AL 1060 For Air Cooler Boiler

Brand Name:	Yuhong
Model Number:	L Type Fin Tube
MOQ:	1 PC
Price:	Negotiable
Packaging Details:	Ply - Wooden Case + Iron Frame
Payment Terms:	TT, LC

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ABS, BV, DNV, CCS, LR

Features:

High Efficiency, Corrosion Resistance, Easy To Clean

Type:

L/LL/KL Type Fin Tube

Base Tube Standard:

ASTM A179, ASME SA179

Fin Materials:

Aluminium, Copper

Bare Tube Diameter(MM):

16-63 Mm

Fin Pitch(MM):

2.1-5 Mm

Fin Height(MM):

<17 Mm

Fin Thick(MM):

~0.4 Mm

Heat Exchanger / Boiler / Furnaces / Condensers / Evaporators / Air Cooler, Etc

Highlight:

Al1060 Spiral Wound Fin Tubes, L Type Spiral Wound Fin Tubes, ASME SA179 Spiral Wound Fin Tubes

Supply Ability:

10000 Tons/Month

Highlight:

ASTM A179 Wound Fin Tube

Boiler Wound Fin Tube

AL 1060 Wound Fin Tube

Product Description

ASTM A179 Wound Fin Tube L Type With Material AL 1060 For Air Cooler,Bolier

The ASTM A179 Wounded Fin Tube design significantly enhances the surface area of the tube, improving heat exchange efficiency and enabling effective thermal transfer in a compact space. AL1060 aluminum alloy has excellent corrosion resistance, making it suitable for various chemical environments and extending the lifespan of the tubes ,making it suitable for various chemical environments and extending the lifespan of the tubes.

The L-fin structure enables high-efficiency heat exchange in limited spaces, making it suitable for compact equipment layouts.These tubes are widely applicable in refrigeration, air conditioning, and petrochemical industries, meeting various operational demands.

Chemical positions:

Grade	C	Si	Mn	P	S	Mo	Cr	V
A179	0.06-0.18	/	0.27-0.63	≤0.035	≤0.035	/	/	/

Mechanical Properties of ASTM A179/A179M:

Tensile Strength (Mpa)	Yield Strength (Mpa)	Elongation (%)	Hardness (HRB)
≥325	≥180	≥35	≤72

Specifications For Various Types Of Finned Tubes:

Yuhong Group Fin Tube Specification
Type	Description	Base tube	Fin specification (mm)
Type	Description	O.D. (mm)	Fin pitch	Fin height	Fin thick
Embedded	G-type fin tube	16-63	2.1-5	<17	~0.4
Extruded	Single metal combined metal	8-51	1.6-10	<17	0.2-0.4
	Low fin tube t-type fin tube	10-38	0.6-2	<1.6	~0.3
	Bamboo tube corrugated tube	16-51	8~30	<2.5	/
Wound	L/KL/LLtype fin tube	16-63	2.1-5	<17	~0.4
String	String fin tube	25-38	2.1-3.5	<20	0.2-0.5
U-type	U-type tube	16-38	/	/	/
Welding	HF-welding fin tube	16-219	3~25	5~30	0.8-3
	H/HH type fin tube	25-63	8~30	<200	1.5-3.5
	Studded fin tube	25-219	8~30	5~30	φ5-20

Advantages:

High Heat Exchange Efficiency
Corrosion Resistance
Lightweight Design
Excellent Thermal Conductivity
Space Efficiency
Versatile Applications
Ease of Maintenance

Applicatons:

Plate heat exchangers
Shell-and-tube heat exchangers.
Industrial cooling towers
Circulation cooling systems
Central air conditioning systems
Split air conditioners
Boilers
Reactors
Evaporators
Heat Pump Systems

ASTM A179 Wound Fin Tube L Type With Material AL 1060 For Air Cooler Boiler 0
