Extruded Fin Tube ASTM A312 TP304 For Heat Exchangers Boilers

Brand Name:	Yuhong
Model Number:	ASTM A312 TP304
MOQ:	1 PC
Price:	Negotiable
Packaging Details:	Ply - Wooden Case + Iron Frame
Payment Terms:	TT, LC

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ABS, BV, DNV, CCS, LR

Base Tube Material Standard:

ASTM A312,ASME SA312

Base Tube Material Grade::

TP304,TP304L,TP304H,TP321

Fin Type:

Extruded Fin Tube

Fin Material:

Aluminum , Copper , Stainless Steel , Carbon Steel

Supply Ability:

10000 Tons/Month

Highlight:

ASTM A312 Extruded Fin Tube

Heat Exchangers Extruded Fin Tube

Boilers Extruded Fin Tube

Product Description

Extruded Fin Tube,ASTM A312 TP304 For Heat Exchanger

ASTM A312 specifies requirements for the chemical composition, mechanical properties, and manufacturing processes, ensuring high-quality stainless steel pipes.ASTM A312 materials can maintain strength and integrity at elevated temperatures, making them ideal for high-temperature applications such as boilers and heat exchangers.

TP304L has excellent resistance to a wide range of corrosive environments, making it suitable for applications in chemical processing and marine environments.The material maintains good strength and stability at elevated temperatures, which is essential for heat exchange applications and P304L is easily weldable, allowing for effective fabrication of complex geometries, which is beneficial for manufacturing fin tubes.

Chemical Composition:

ASTM A312 TP304 Chemical Composition (%)

Result

≤0.08%

≤0.75%

≤2.00%

≤0.045%

≤0.030%

18.0%-20%

Fin Tube type:

Yuhong Group Fin Tube Specification
Type	Description	Base tube	Fin specification (mm)
Type	Description	O.D. (mm)	Fin pitch	Fin height	Fin thick
Embedded	G-type fin tube	16-63	2.1-5	<17	~0.4
Extruded	Single metal combined metal	8-51	1.6-10	<17	0.2-0.4
	Low fin tube t-type fin tube	10-38	0.6-2	<1.6	~0.3
	Bamboo tube corrugated tube	16-51	8~30	<2.5	/
Wound	L/KL/LLtype fin tube	16-63	2.1-5	<17	~0.4
String	String fin tube	25-38	2.1-3.5	<20	0.2-0.5
U-type	U-type tube	16-38	/	/	/
Welding	HF-welding fin tube	16-219	3~25	5~30	0.8-3
	H/HH type fin tube	25-63	8~30	<200	1.5-3.5
	Studded fin tube	25-219	8~30	5~30	φ5-2

Applications:

Heat Exchangers
Condensers
Boilers
Chillers
Radiators
Evaporators
Cooling Towers
Chemical Process Equipment

Extruded Fin Tube ASTM A312 TP304 For Heat Exchangers Boilers 0
