ASME SA213 TP316L Stainless Steel Seamless Heat Exchanger Tube For Power Generation

Brand Name:	Yuhong
Model Number:	Seamless Tube
MOQ:	1 PC
Price:	Negotiable
Packaging Details:	Ply-Wooden Case & Woven Bag
Payment Terms:	TT, LC

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ABS, BV, DNV, CCS, LR

Material:

TP316L

Standard:

ASME SA213 , ASTM A213

Ends:

PE , BE

Testing:

HT , ET

Size:

1/2 Inch - 98 Inch

Application:

Heat Exchanger

Supply Ability:

10000 Tons/Month

Highlight:

TP316L Stainless Steel Heat Exchanger Tube

Seamless stainless steel heat exchanger tube

Heat Exchanger Tube For Power Generation

Product Description

ASME SA213 TP316L Stainless Steel Seamless Heat Exchanger Tube For Power Generation

Grade TP316L is a low-carbon austenitic stainless steel with excellent corrosion resistance, especially against sulfuric and chloric acids.

This material offers excellent corrosion resistance, good weldability, and high and low-temperature performance, making it commonly used in the chemical processing, petrochemical, pharmaceutical, food and beverage, and marine industries. TP316L exhibits good tensile strength, ductility, and weldability. Its low carbon content reduces the risk of carbide precipitation during welding, maintaining corrosion resistance in the heat-affected zone.

ASME SA213 outlines the standards for seamless and welded tubes intended for high-pressure and high-temperature service. The specification ensures that the tubes meet stringent quality and performance criteria.

Chemical Composition:

Grade	Cr	Ni	Mo	C
SA213 TP316L	16.0–18.0%	10.0–14.0%	2.0–3.0%	≤ 0.03%

Mechanical Properties:

Grade	Yield Strength	Tensile Strength	Elongation	Hardness
SA213 TP316L	≥ 170 MPa (25 ksi)	≥ 485 MPa (70 ksi)	≥ 35% in 50 mm	Typically ≤ 90 HRB

Key Features:

Material Composition:TP316L Stainless Steel: Contains chromium (16-18%), nickel (10-14%), and molybdenum (2-3%).
Corrosion Resistance: Excellent resistance to chloride environments, reducing pitting and crevice corrosion.
Weldability: Low carbon content improves weldability and minimizes carbide precipitation.
Durability: Maintains structural integrity under moderate to high temperatures and pressures.

Applications:

Chemical Processing: Used in heat exchangers for reactions and separations, handling corrosive chemicals at high temperatures.
Oil and Gas: Employed in pipelines and heat exchangers for processing oil and gas, where durability and resistance to harsh environments are essential.
Power Generation: Employed in steam generators and heat recovery systems, particularly in nuclear and fossil fuel power plants.
Pharmaceuticals: Applied in processes requiring strict hygiene standards and resistance to aggressive cleaning agents.

ASME SA213 TP316L Stainless Steel Seamless Heat Exchanger Tube For Power Generation 0
