ASME SA213 TP304L 1.4307 SUS304L 03Х18Н11 Stainless Steel Heat Exchanger Tube

Brand Name:	Yuhong
Model Number:	Seamless Tube
MOQ:	1 PC
Price:	Negotiable
Packaging Details:	Ply-Wooden Case & Woven Bag
Payment Terms:	TT, LC

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ABS, BV, DNV, CCS, LR

Material:

TP304L, 1.4307, SUS304L, 03X18H11

Standard:

ASME SA213 , ASTM A213

Ends:

PE , BE

Testing:

UT, ET, HT, PMI

Size:

OD : 6mm~ 50.8mm , WT: 0.5mm~ 15mm, L: Max:34m/pc

Application:

Heat Exchanger, Cooling , Heating, Condenser, Tube Bundle

Supply Ability:

10000 Tons/Month

Highlight:

1.4307 Stainless Steel Heat Exchanger Tube

SUS304L Stainless Steel Heat Exchanger Tube

ASME Stainless Steel Heat Exchanger Tube

Product Description

ASME SA213 TP304L (1.4307, SUS304L,03Х18Н11) Stainless Steel Heat Exchanger Tube

Grade TP304L is a low-carbon version of the 304 stainless steel alloy. The lower carbon content minimizes carbide precipitation during welding, which improves its resistance to intergranular corrosion. TP304L is an austenitic stainless steel that is widely used in various applications due to its excellent corrosion resistance, formability, and weldability.

Stainless Steel ASME SA213 TP304L Heat Exchanger Tube is designed for applications requiring excellent corrosion resistance and weldability. Made from TP304L, a low-carbon austenitic stainless steel, it minimizes the risk of carbide precipitation during welding.

Chemical Composition:

Grade	Cr	Ni	C
SA213 TP304L	18.0–20.0%	8.0–12.0%	≤ 0.03%

Mechanical Properties:

Grade	Ultimate Tensile Strength	Yield Strength (0.2% Offset)	Elongation	Hardness
SA213 TP304L	≥ 170 MPa (25 ksi)	≥ 485 MPa (70 ksi)	≥ 35% in 50 mm	Typically ≤ 90 HRB

Key Features:

Material Composition:TP304L Stainless Steel: Contains chromium (18-20%) and nickel (8-12%).
Corrosion Resistance: Outstanding resistance to a wide range of environments and chemicals.
Weldability: Low carbon content enhances weldability and reduces carbide precipitation.
Durability: Maintains structural integrity under moderate temperatures and pressures.

Applications:

1. Chemical Processing

Heat Exchangers:Ideal for handling corrosive chemicals and high temperatures.Ensures long-lasting performance.
Process Piping:Suitable for environments requiring superior corrosion resistance.

2. Food and Beverage Industry

Processing Equipment:Maintains hygiene and resists corrosion from food acids.Used in dairy and brewery systems.

3. Pharmaceutical Industry

Sanitary Tubing:Ensures cleanliness and resists corrosion in sensitive processes.Ideal for equipment exposed to harsh cleaning agents.

4. Marine Applications

Seawater Systems:Resists pitting and crevice corrosion in marine environments.Provides durability in harsh conditions.

5. Water Treatment

Desalination Plants:Efficient in handling saline solutions.Provides long-term reliability and resistance.

ASME SA213 TP304L 1.4307 SUS304L 03Х18Н11 Stainless Steel Heat Exchanger Tube 0
