Stainless Steel Heat Exchanger Tube ASTM A213 TP316 100% Hydrostatic Test And Eddy Current Test

Brand Name:	Yuhong
Model Number:	Seamless Tube
MOQ:	1 PC
Price:	Negotiable
Packaging Details:	Ply-Wooden Case & Woven Bag
Payment Terms:	TT, LC

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ABS, BV, DNV, CCS, LR

Material:

TP316

Standard:

ASTM A213 , ASME SA213

Ends:

PE , BE

Testing:

UT, ET, HT, PMI

Size:

OD : 6mm~ 50.8mm , WT: 0.5mm~ 15mm, L: Max:34m/pc

Application:

Heat Exchanger, Cooling , Heating, Condenser, Tube Bundle

Supply Ability:

10000 Tons/Month

Highlight:

ASTM A213 Heat Exchanger Tube

Eddy Current Test Heat Exchanger Tube

100% Hydrostatic Test Heat Exchanger Tube

Product Description

Stainless Steel Heat Exchanger Tube , ASTM A213 TP316 , 100% Hydrostatic Test and Eddy Current Test

TP316 exhibits good mechanical properties, including high tensile strength, good ductility, and excellent weldability. It can withstand elevated temperatures without losing strength. TP316 can be heat treated to improve its mechanical properties, although it is not typically necessary for most applications. ASTM A213 specifies seamless ferritic and austenitic alloy-steel boiler, superheater, and heat-exchanger tubes.

The Stainless Steel ASTM A213 TP316 Heat Exchanger Tube is a versatile and efficient solution for heat transfer applications across various industries. Its robust design and superior material properties make it ideal for chemical processing, food and beverage, pharmaceutical, marine, and desalination applications. The tube ensures long-lasting performance, improved system efficiency, and resistance to corrosion in demanding environments.

Chemical Composition:

Grade	Cr	Ni	Mo	C
TP316	16.00-18.00%	10.0-14.0%	2.0-3.0%	0.08% max

Mechanical Properties:

Grade	Yield Strength:	Tensile Strength	Elongation	Hardness
TP316	≥ 205 MPa (30 ksi)	≥ 515 MPa (75 ksi)	≥ 35% in 50 mm	Typically ≤ 95 HRB

Applications:

Petrochemical Industry: Used in heat exchangers, reactors, and pipelines for processing and transporting oil, gas, and chemicals.
Power Generation: Employed in steam generators, boilers, and condensers to manage heat transfer effectively.
Food and Beverage Industry: Suitable for heat exchangers in pasteurization, sterilization, and refrigeration processes, where hygiene is critical.
Pharmaceuticals: Utilized in processes requiring high cleanliness and resistance to corrosion, such as in heat exchangers and reaction vessels.
Marine Applications: Ideal for seawater cooling systems and other marine environments due to its resistance to corrosion from saltwater.
Pulp and Paper Industry: Used in recovery boilers and heat exchangers where chemical exposure is common.
HVAC Systems: Incorporated in systems that require reliable heat exchange in heating and cooling applications.
Chemical Processing: Employed in various chemical reactors and heat exchangers that require resistance to aggressive media.

Stainless Steel Heat Exchanger Tube ASTM A213 TP316 100% Hydrostatic Test And Eddy Current Test 0
