Stainless Steel Welded ASTM A269 TP316L Heat Exchanger Tube

Brand Name:	Yuhong
Model Number:	WELDED
MOQ:	1 PC
Price:	Negotiable
Packaging Details:	Ply-Wooden Case & Woven Bag
Payment Terms:	TT, LC

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ABS, BV, DNV, CCS, LR

Material:

TP316L

Standard:

ASTM A269 , ASME SA269

Ends:

PE , BE

Testing:

UT, ET, HT, PMI

Size:

OD : 6mm~ 50.8mm , WT: 0.5mm~ 15mm, L: Max:34m/pc

Application:

Heat Exchanger, Cooling , Heating, Condenser, Tube Bundle

Supply Ability:

10000 Tons/Month

Highlight:

Heat Exchanger Stainless Steel Welded Tube

TP316L Stainless Steel Welded Tube

Welded stainless steel heat exchanger tube

Product Description

Stainless Steel Welded Tube, ASTM A269 TP316L, Heat Exchanger Tube

ASTM A269 TP316L Stainless Steel Heat Exchanger Tube, is a high-quality tubing option designed for optimal heat transfer in corrosive environments. Made from TP316L stainless steel, it offers excellent corrosion resistance and durability. ASTM A269 is the standard specification for seamless and welded austenitic stainless steel tubing for general service. TP316L refers to the specific grade and type of the material. TP316L offers good mechanical properties, including high tensile strength and elongation, as well as good weldability and formability.

Chemical Composition:

Grade	Cr	Ni	Mo	C
TP316L	16.00-28.00%	10.0-14.0%	2.0-3.0%	0.03% max

Mechanical Properties:

Grade	Yield Strength:	Tensile Strength	Elongation	Hardness
TP316L	≥ 170 MPa (25 ksi)	≥ 485 MPa (70 ksi)	≥ 35% in 50 mm	Typically ≤ 95 HRB

Applications:

1. Chemical Processing

Heat Exchangers: Suitable for handling corrosive chemicals and high temperatures. Ensures consistent performance and longevity in chemical plants.
Reactors: Maintains optimal temperature control for chemical reactions. Enhances process efficiency and safety.

2. Food and Beverage Industry

Pasteurizers and Sterilizers: Used in equipment requiring high corrosion resistance. Ensures hygiene and safety in food processing.

3. Pharmaceutical Industry

Process Heaters and Coolers: Ideal for applications requiring stringent cleanliness and corrosion resistance. Maintains precise temperature control of sensitive processes.

4. Marine Applications

Heat Exchangers: Effective in environments with high chloride exposure. Resists pitting and crevice corrosion.

5. Desalination Plants

Evaporator Tubes: Suitable for handling saline solutions. Provides durability and resistance to corrosion.

Stainless Steel Welded ASTM A269 TP316L Heat Exchanger Tube 0
