Heat Exchanger Tube ASTM A312 TP316L For Power Generation

Brand Name:	Yuhong
Model Number:	Seamless Tube
MOQ:	1 PC
Price:	Negotiable
Packaging Details:	Ply-Wooden Case & Woven Bag
Payment Terms:	TT, LC

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ABS, BV, DNV, CCS, LR

Material:

TP316L

Standard:

ASTM A312 , ASME SA312

Ends:

PE , BE

Testing:

UT, ET, HT, PMI

Size:

OD : 6mm~ 50.8mm , WT: 0.5mm~ 15mm, L: Max:34m/pc

Application:

Heat Exchanger, Cooling , Heating, Condenser, Tube Bundle

Supply Ability:

10000 Tons/Month

Highlight:

TP316L Heat Exchanger Tube

ASTM A312 Heat Exchanger Tube

Power Generation Heat Exchanger Tube

Product Description

Heat Exchanger Tube ASTM A312 TP316L For Power Generation

Stainless Steel ASTM A312 TP316L Heat Exchanger Tube is a high-performance tube designed for efficient heat transfer, particularly in corrosive environments. Made from TP316L stainless steel, it offers excellent corrosion resistance and strength. TP316L Stainless Steel: Low carbon content for improved weldability and reduced carbide precipitation. Maintains structural integrity under varying temperatures and mechanical stress. Suitable for applications requiring frequent welding.

Chemical Composition:

Grade	Cr	Ni	Mo	C
TP316L	16.00-28.00%	10.0-14.0%	2.0-3.0%	0.03% max

Mechanical Properties:

Grade	Yield Strength:	Tensile Strength	Elongation	Hardness
TP316L	≥ 170 MPa (25 ksi)	≥ 485 MPa (70 ksi)	≥ 35% in 50 mm	Typically ≤ 95 HRB

Applications:

Petrochemical Industry: Used in heat exchangers, reactors, and piping systems for refining and processing petroleum products.
Power Generation: Employed in steam boilers, condensers, and heat recovery systems to manage heat exchange efficiently.
Marine Applications: Ideal for seawater cooling systems, heat exchangers, and other components exposed to corrosive marine environments.
Chemical Processing: Utilized in various chemical reactors and heat exchangers where resistance to aggressive chemicals is essential.
Food and Beverage Industry: Suitable for heat exchangers in pasteurization and sterilization processes, where hygiene is paramount.
Pharmaceutical Manufacturing: Commonly used in processes that require high levels of cleanliness and resistance to corrosion.
HVAC Systems: Incorporated in heating and cooling applications where reliable heat transfer is necessary.
Pulp and Paper Industry: Used in recovery boilers and heat exchangers, where exposure to chemicals is prevalent.

Heat Exchanger Tube ASTM A312 TP316L For Power Generation 0
