Tubesheets made from ASTM A182 F304 provide robust support and precise alignment for the tubes, ensuring efficient heat transfer and structural integrity. It ensures a secure and leak-tight seal between the tubes and the shell, preventing cross-contamination of fluids. The characteristics of grade 304 make it suitable for demanding environments in industries such as power generation, chemical processing.

Chemical Composition:

Grade	Cr	Ni	C	Mn	Si	P	S	N	Fe
304	18-20%	8-10.5%	0.08% max	2% max	1% max	0.045% max	0.03% max	0.10% max	Balance

Mechanical Properties:

Grade

Tensile Strength

Yield Strength

Elongation

Hardness

304

Minimum 515 MPa

(75,000 psi)

Minimum 205 MPa

(30,000 psi)

Minimum 40% in 50 mm

(2 inches)

Maximum 201 HB

(Brinell hardness)

Applications:

Good formability and Excellent weldability, makes it suitable for many applications:

1. Shell and Tube Heat Exchangers

2. Plate Heat Exchangers:

End Plates: Used as end plates in plate heat exchangers, providing structural support and maintaining the integrity of the heat exchanger assembly.
Gasket Sealing: Works in conjunction with gaskets to ensure a tight seal between plates, preventing fluid leakage.
