ASME SB163 Ni200 Nickel / Nickel Alloy Steel Heat Exchanger Tube

Brand Name:	Yuhong
Model Number:	Seamless Tube
MOQ:	1 PC
Price:	Negotiable
Packaging Details:	Ply-Wooden Case & Woven Bag
Payment Terms:	TT, LC

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ABS, BV, DNV, CCS, LR

Material:

Ni200

Standard:

ASME SB163 , ASTM B163

Ends:

PE , BE

Testing:

HT , ET

Size:

1/2 Inch - 98 Inch

Application:

Heat Exchanger

Supply Ability:

10000 Tons/Month

Highlight:

ASME SB163 nickel alloy tube

nickel alloy tube Highly ductile

nickel 200 pipe 148 MPa

Product Description

ASME SB163 Ni200 Nickel / Nickel Alloy Steel Heat Exchanger Tube

Grade Ni200 is a commercially pure wrought nickel with a nickel content of at least 99.6%. It is known for its excellent mechanical properties, corrosion resistance, and high thermal and electrical conductivity. Ni200 is highly ductile and can withstand a wide range of temperatures, making it suitable for various industrial applications.

Chemical Composition:

Grade	Ni	Cu	Fe	Mn	Si	C	S
Ni200	≥ 99.0%	≤ 0.25%	≤ 0.40%	≤ 0.35%	≤ 0.35%	≤ 0.15%	≤ 0.01%

Mechanical Properties:

Grade

Tensile Strength

Yield Strength

Elongation

Hardness

Ni200

Minimum 462 MPa (67,000 psi)

Minimum 148 MPa (21,500 psi)

40% minimum in

50 mm

Maximum 70 HRB (Rockwell Hardness B)

Key Features:

Corrosion Resistance: Excellent resistance to a wide range of corrosive environments, including acids, alkalis, and neutral salts.
Thermal Conductivity: High thermal conductivity, making it effective for heat transfer applications.
Electrical Conductivity: High electrical conductivity, suitable for electrical and electronic components.
Ductility: Highly ductile, allowing for easy fabrication and forming.

Applications:

1. Chemical Processing Industry

Heat Exchangers: Used in heat exchangers where resistance to corrosive chemicals, including acids and alkalis, is essential.
Reactors and Pressure Vessels: Suitable for reactors and pressure vessels dealing with highly corrosive substances.
Piping Systems: Ideal for piping systems that transport aggressive chemicals at various temperatures and pressures.

2. Petrochemical Industry

Catalyst Supports: Used in catalyst supports due to its chemical stability and resistance to high temperatures.
Heat Exchangers: Suitable for heat exchangers in petrochemical plants where exposure to corrosive substances is common.
Distillation Columns: Ideal for components in distillation columns handling aggressive chemicals.

3. Marine Applications

Seawater Systems: Used in marine environments for seawater cooling and heating systems due to its excellent resistance to corrosion.
Shipbuilding: Suitable for shipbuilding where components are exposed to seawater and must resist corrosion.
Desalination Plants: Ideal for desalination plant tubing where high resistance to saline environments is necessary.

ASME SB163 Ni200 Nickel / Nickel Alloy Steel Heat Exchanger Tube 0
