| Brand Name: | Yuhong |
| Model Number: | ASTM B111 C70600 |
| MOQ: | 100KGS |
| Price: | Negotiable |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 1000 tons per month |
| Attribute | Value |
|---|---|
| Fin Tube Type | Low Fin Tubes |
| Test | Hydro test and Pneumatic test |
| Base Tube Material | ASTM B111 C70600 |
| FPI | 26 |
| Fin height | 1.3mm |
| Application | Heat Exchanger |
| Element | Content (%) |
|---|---|
| Copper (Cu) | ≥ 88.6 (balance) |
| Nickel (Ni) | 9.0 - 11.0 |
| Iron (Fe) | 1.0 - 1.8 |
| Manganese (Mn) | ≤ 1.0 |
| Zinc (Zn) | ≤ 1.0 |
| Lead (Pb) | ≤ 0.05 |
| Property | Value |
|---|---|
| Tensile Strength | ≥ 310 MPa (45 ksi) |
| Yield Strength (0.5%) | ≥ 105 MPa (15 ksi) |
| Elongation (2") | ≥ 30% |
| Hardness (HRB) | ≤ 100 |
