Attribute	Value
Fin Wall thickness	0.8-3mm
Base Tube Material	TP304, TP304L, TP304H, TP316, TP316L, TP321 TP347
Fin pitch	FPI: 3-25
Fin Material	AISI 304,316,409,410,321,347
Fin height	5-30mm
Length	Max 34M/PC

Product Description

Material: Made from stainless steel grade 304H, known for high-temperature strength and corrosion resistance.

Fin Type: Serrated fins enhance heat transfer by increasing the surface area.

Dimensions: Available in various diameters and lengths to suit different applications.

Manufacturing Standards: Conforms to ASTM A312 specifications, ensuring quality and reliability.

Key Features

Heat Transfer Efficiency: Serrated fins improve thermal performance by promoting turbulent flow.
Durability: Resistant to oxidation and scaling at elevated temperatures.
Versatility: Suitable for both high-pressure and high-temperature applications.
Corrosion Resistance: Excellent resistance to corrosive environments, making it suitable for various industrial applications.

Operating Principles

Heat Exchange: The fins increase the surface area for heat transfer, allowing more efficient thermal exchange between fluids.

Fluid Dynamics: The serrated design disrupts laminar flow, promoting turbulence to enhance heat transfer rates.

Applications

Power Generation: Used in heat exchangers, condensers, and boilers in power plants.
Chemical Processing: Ideal for heat exchangers in chemical reactors and distillation columns.
Oil and Gas: Employed in cooling systems and heat recovery units.
HVAC Systems: Utilized in air conditioning and refrigeration systems for improved efficiency.

Product Advantages

Improved Efficiency: Higher heat transfer rates lead to lower energy costs.
Extended Service Life: Corrosion resistance and durability lead to longer equipment life.
Cost-Effective: Reduced energy consumption translates to lower operational costs.
Customization: Can be tailored to specific applications and performance requirements.

Frequently Asked Questions

Q1: What are serrated fin tubes?

A1: Serrated fin tubes are heat exchangers with serrated fins to enhance heat transfer efficiency.

Q2: How do serrated fins improve efficiency?

A2: Serrated fins disrupt laminar flow, creating turbulence that increases heat exchange rates.

Q3: What temperatures can ASTM A312 TP304H withstand?

A3: TP304H can withstand temperatures up to 1000°F (537°C) in continuous service and higher in intermittent service.

Q4: How do I choose the right size of serrated fin tube?

A4: Selection depends on the required heat transfer rate, fluid properties, and system design. Consulting with a specialist is recommended.

Q5: What maintenance is required for serrated fin tubes?

A5: Regular inspections for corrosion, scaling, and mechanical damage are crucial. Cleaning may be necessary based on the application.
