ASTM A213 T22 Alloy Steel Serrated Fin Tube for Furnace

Brand Name:	Yuhong
Model Number:	ASTM A213 T22
MOQ:	100 KGS
Price:	Negotiate
Packaging Details:	ply-wooden case with iron frame
Payment Terms:	L/C,T/T

Detail Information

Product Description

Ratings & Reviews

Detail Information

Place of Origin:

China

Certification:

ABS, CCS, BV, LR, DNV

Packing:

Ply-wooden Case With Iron Frame

Base Pipe Material:

P9, P22

Welding Type:

HFW , Serrated

Production Process:

Cold Drawn

Operating Temperature:

Fin Thickness:

1.8-3mm

ET, HT

Supply Ability:

1000 tons per month

Highlight:

ASTM A213 T22 alloy steel fin tube

serrated fin tube for furnace

alloy steel serrated finned tube

Product Description

ASTM A213 T22 Alloy Steel Fin Tube, Serrated Fin Tube With CS Fin For Furnace

Product Attributes

Attribute	Value
Packing	Ply-wooden Case With Iron Frame
Base Pipe Material	P9, P22
Welding Type	HFW, serrated
Production Process	Cold Drawn
Operating Temperature	300℃
Fin Thickness	1.8-3mm
NDT	ET, HT

Product Overview

The ASTM A213 T22 Alloy Steel Serrated Fin Tube is designed for high-temperature applications in furnace convection sections and other thermal systems. The base tube is made from T22 alloy steel, and the serrated carbon steel fins are welded onto the tube surface. The serrated fin design increases the surface area, promoting efficient heat transfer and making it suitable for applications where high thermal efficiency and durability are required.

Chemical Composition - ASTM A213 T22 (Base Tube)

Element	Content (%)
C	0.08-0.15
Mn	0.30-0.60
P	≤ 0.025
S	≤ 0.025
Si	0.50-0.80
Cr	2.00-2.50
Mo	1.00-1.20
Fe	Balance

Mechanical Properties - ASTM A213 T22 (Base Tube)

Property	Value
Tensile Strength	≥ 415 MPa
Yield Strength	≥ 205 MPa
Elongation	≥ 30%
Hardness	≤ 192 HB
Max Operating Temp	~ 600°C (1112°F)

Fin Material - Carbon Steel (CS Fin)

Element	Content (%)
C	≤ 0.22
Mn	0.30-0.70
P	≤ 0.045
S	≤ 0.050
Fe	Balance

Advantages

Enhanced Heat Transfer
The serrated fin design maximizes the heat transfer rate by breaking the boundary layer and promoting better turbulence in the gas flow, which improves the thermal efficiency of the furnace.
High-Temperature Performance
ASTM A213 T22 alloy steel is specifically engineered for high-temperature and high-pressure environments, providing excellent creep resistance and oxidation resistance.
Durability
The carbon steel fins are securely welded to the base tube, ensuring durability and resistance to mechanical wear and tear, especially in furnace and boiler environments.
Corrosion Resistance
The combination of alloy steel tube and carbon steel fins resists corrosion, making this fin tube ideal for applications in high-temperature flue gas streams.
Cost-Effective
Compared to other fin materials like stainless steel, carbon steel offers a more cost-effective solution while still maintaining good thermal conductivity and mechanical strength.

Applications

Convection Sections of Furnaces
In fired heaters and industrial furnaces, where heat needs to be transferred from flue gases to process fluids.
Power Plant Boilers
Used in economizers and superheaters for heat recovery from flue gases.
Petrochemical and Chemical Plants
Suitable for applications where efficient heat exchange is needed for steam generation or process heating.
Heat Recovery Systems
Ideal for waste heat recovery units where thermal energy from exhaust gases is recovered and reused.
