ASTM A376 TP347H Stainless Steel Solid HF Welding Fin Tube For Convection Coil Tube

Brand Name:	Yuhong
Model Number:	ASTM A376 TP347H
MOQ:	100kgs
Price:	Negotiable
Packaging Details:	ply-wooden case with iron case
Payment Terms:	L/C,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ABS, CCS, BV, LR, DNV

Base Tube:

16mm-219mm

Fin Wall Thickness:

0.8-3mm

Fin Pitch:

1 Inch

Fin Thk:

9.07mm

Tube Standard:

ASTM A376

Dimensions:

88.9mm, 114.3mm, 168.3mm, Etc.

Fins:

TP347H

Corrosion Resistance:

Pipe Length:

Customsized

Welding Area:

According To Actual Demand

Highlight:

ASTM A376 Solid Fin Tube

TP347H Solid Fin Tube

Product Description

ASTM A376 TP347H Stainless Steel Solid Fin Tube, HF Welding Fin Tube, For Convection Coil Tube

Product Specifications

Attribute	Value
Base Tube	16mm-219mm
Fin Wall Thickness	0.8-3mm
Fin Pitch	1 inch
Fin Thickness	9.07mm
Tube Standard	ASTM A376
Dimensions	88.9mm, 114.3mm, 168.3mm, etc.
Fins	TP347H
Corrosion Resistance	High
Pipe Length	Custom-sized
Welding Area	According to actual demand

Product Overview

Yuhong specializes in heat exchanger tubes, fin tubes, and boiler tubes. With 12 years of experience exporting fin tubes, we have earned the trust of clients from over 80 countries. Our product range includes G Type fin tubes, extruded fin tubes, wound fin tubes, HFW fin tubes, and low fin tubes.

The ASTM A376 TP347H solid fin tube is engineered for high-temperature heat transfer systems, particularly in convection coil sections of boilers and furnaces. Constructed from seamless TP347H stainless steel, the tube features externally finned surfaces using solid carbon steel or stainless steel strips bonded through high-frequency welding (HFW), significantly enhancing heat exchange efficiency in compact designs.

Chemical Composition (TP347H Tube)

Element	Content (%)
C	0.04 - 0.10
Mn	≤ 2.00
Si	≤ 1.00
P	≤ 0.040
S	≤ 0.030
Cr	17.0 - 19.0
Ni	9.0 - 13.0
Nb (Cb)	8×C - 1.10
Fe	Balance

Mechanical Properties

Property	Value (TP347H)
Tensile Strength	≥ 515 MPa
Yield Strength	≥ 205 MPa
Elongation	≥ 35%
Hardness	≤ 95 HRB
Max. Operating Temp	~1050°C

Key Advantages

High Temperature Strength: Stabilized with niobium (Nb) for superior creep resistance at elevated temperatures.
Enhanced Heat Transfer: Solid fins provide greater surface area for efficient heat dissipation in convection zones.
High Welding Integrity: High-frequency welding delivers tight fin-to-tube bonding, even under thermal cycling.
Corrosion and Oxidation Resistant: Excellent resistance to scaling and corrosion in flue gas environments.
Long Service Life: Durable construction ideal for continuous-duty, high-heat applications.

Typical Applications

Used primarily in the convection section of:

Fired Heaters (Oil & Gas)
Industrial Furnaces
Power Plant Boilers
Heat Recovery Units
Steam Superheaters

These tubes are installed horizontally or vertically where they absorb convective heat from flue gases after the radiant zone.
