ASME SA209 Type G Embedded Finned Tubes With Aluminum 1060 Fins For High Temperature Heat Exchangers

Brand Name:	Yuhong
Model Number:	ASME SA209
MOQ:	200-500KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Cases with Steel Frames(both ends of pipes have plastic caps)
Payment Terms:	TT, LC

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ABS, BV, DNV, CCS, LR

Fin Pitch:

2.1-5

Fin Height:

Fin Thick:

Application:

Air Cooler, Cooling Tower , Heat Exchanger

Fin Material:

Aluminum 1060

Supply Ability:

According to Clients'reguirements

Highlight:

High Temperature Embedded Finned Tubes

Aluminum 1060 Embedded Finned Tubes

ASME SA209 Embedded Finned Tubes

Product Description

1. What is ASME SA209 Type G Embedded Finned Tube with Aluminum 1060?

The ASME SA209 Type G Embedded Finned Tube with Aluminum 1060 is an advanced heat transfer solution engineered for high-temperature and high-pressure environments. It features a seamless carbon-molybdenum alloy steel base tube (ASME SA209 Grade T1/T1a) with Aluminum 1060 fins (99.6% pure aluminum) mechanically embedded into precision-machined grooves on the tube surface. This innovative "G-Type" design ensures a secure, gap-free bond between the base metal and fins, combining the high-temperature strength of SA209 steel with the lightweight, ultra-high thermal conductivity of aluminum. Ideal for boilers, superheaters, and corrosive industrial systems, it delivers unmatched efficiency, durability, and corrosion resistance.

2. Chemical & Mechanical Properties

Chemical Properties

Component	Chemical Composition	Key Features
ASME SA209 Base Tube	• C: 0.15–0.25%, Mo: 0.44–0.65%, Mn: 0.30–0.80%, Si: 0.10–0.50%.	• Excellent oxidation resistance up to 540°C (1000°F). • Resists steam corrosion and scaling.
Aluminum 1060 Fins	• Al: 99.6% min, Fe+Si: ≤0.40%, Cu: ≤0.05%.	• Superior thermal conductivity (235 W/m·K). • Non-reactive in humid/alkaline conditions.
Synergy	• Electrically insulated bonding prevents galvanic corrosion between steel and aluminum.	• Ideal for steam/water systems with thermal cycling.

Mechanical Properties

Component	Mechanical Performance	Key Features
ASME SA209 Base Tube	• Tensile Strength: 415–585 MPa • Yield Strength: 205 MPa (min) • Hardness: 170–220 HB.	• High-pressure tolerance (up to 25 MPa). • Creep-resistant for long-term high-temperature use.
Aluminum 1060 Fins	• Tensile Strength: 70–110 MPa • Elongation: 15–25% • Hardness: 23 HB.	• Lightweight design reduces system load. • Ductile for vibration absorption.
Bond Performance	• Shear Strength: ≥55 MPa at fin-tube interface. • Thermal Cycling: Stable under ΔT up to 400°C.	• Zero fin loosening under extreme conditions.

3. Key Applications

• Power Generation: Superheaters, boilers, and economizers in coal/gas-fired plants.

• Petrochemicals: Heat exchangers for steam reforming and catalytic cracking units.

• Marine Systems: High-efficiency condensers for ship engines and offshore platforms.

• Industrial Heating: Process heaters and waste heat recovery in chemical plants.

• Renewable Energy: Biomass boilers and thermal storage systems.

4. Why Choose ASME SA209 Type G + Aluminum 1060 Finned Tubes?

• 30% Higher Heat Transfer Rate vs. traditional welded fin tubes.
• Zero Corrosion Risk: Patented bonding technology isolates steel and aluminum.
• ASME-Certified Reliability: Guaranteed performance in critical high-pressure systems.
• 20% Energy Savings due to lightweight, high-conductivity aluminum fins.
• Global Compliance: Meets ASME SA209, ASTM B209, and ISO 9001 standards.

ASME SA209 Type G Embedded Finned Tubes With Aluminum 1060 Fins For High Temperature Heat Exchangers 0
