ASME SA192 Serrated Finned Tube HF Welding For Industrial Heaters Enhanced Heat Transfer Design

Brand Name:	Yuhong
Model Number:	ASME SA192 Serrated Finned Tube
MOQ:	100 KGS
Price:	Negotiable
Packaging Details:	Plywooden case with Iron Frame
Payment Terms:	TT, LC

Detail Information

Product Description

Ratings & Reviews

Detail Information

Place of Origin:

China

Certification:

ABS, BV, DNV, CCS, LR

Product Name:

Serrated Finned Tube

Type:

High Frequency Welded Serrated Finned Tube

Application:

Heater Parts, Refrigeration Parts, Fluid Cooling

Dimensions:

88.9mm, 101.6mm, 114.3mm, 168.3mm, Etc.

Length:

1-20000mm

Fin Height:

4-17mm

Tube Material:

Carbon Steel, Stainless Steel, Alloy Steel, Copper Etc

Fin Material:

Carbon Steel, Stainless Steel And Alloy Steel Etc

Warranty:

6 Months

Welding Area:

According To Actual Demand

Supply Ability:

4150 Ton Per Month

Highlight:

Industrial Heaters Serrated Finned Tube

Enhanced Heat Transfer Serrated Finned Tube

HF Welding Serrated Finned Tube

Product Description

ASME SA192 Serrated Finned Tube HF Welding For Industrial Heaters Enhanced Heat Transfer Design
Product Specifications:
Base Tube Standard: ASME SA192

Parameter	Specification
Tube OD	19-114.3mm
Wall Thickness	2.11-11.13mm
Fin Height	9-25mm
fin Thickness	0.8-1.2mm
Fin Density	2-7 fins per inch
Length	Up to 24m

Chemical Composition (Base Tube):

Element	C	Mn	P	S	Si
%	0.06-0.18	0.27-0.63	≤0.035	≤0.035	≤0.25

Mechanical Properties:

Tensile Strength: ≥345 MPa
Yield Strength: ≥180 MPa
Elongation: ≥30%

Key Features:

High-frequency welded fins for superior bonding
Serrated fin design for enhanced heat transfer
Excellent thermal efficiency
Superior mechanical strength
Uniform fin spacing
Extended service life
Optimized pressure drop characteristics

Manufacturing Process:

Base tube inspection
Fin strip preparation
High-frequency welding
Serration forming
Quality testing
Surface treatment
Final inspection

Performance Advantages:

Feature	Benefit
Serrated Fin Design	+25-30% Heat Transfer
HF Welding	100% Fin-Tube Bond
Optimized Spacing	Reduced Foulding

Applications:

Industrial fired heaters
Waste heat recovery units
Process gas coolers
Steam generators
Power plant economizers
Industrial furnaces

Quality Assurance:

ISO 9001:2015 certified
ASME certified facility
100% inspection of fin welding
Hydrostatic testing
Eddy current testing available
Third-party inspection support

Frequently Asked Questions:

Q: What is the maximum operating temperature?
A: Up to 450°C (842°F) for continuous service

Q: What fin materials are available?
A: Carbon steel, stainless steel, and special alloys

Q: What are the standard quality tests?
A: Hydrostatic testing, fin adhesion testing, and dimensional inspection

Manufacturing Capabilities:

Annual production capacity: 500,000 meters
Advanced fin welding equipment
Automated production lines
Strict quality control system

About Yuhong Holding Group:

Yuhong Holding Group - Your Premier Manufacturer of Advanced Heat Exchange Solutions

With 20 years of export excellence serving 80 countries, Yuhong Holding Group stands among China's top 5 finned tube exporters. Our 20,000-square-meter facility with 55 production lines ensures superior manufacturing capabilities.

Our team of 110+ professionals combines advanced technology with stringent quality control to deliver exceptional products. Our commitment to innovation and customer satisfaction has earned us trust worldwide.

Contact our technical team today for detailed specifications and customized solutions.

ASME SA192 Serrated Finned Tube HF Welding For Industrial Heaters Enhanced Heat Transfer Design 0

Ratings & Review

Overall Rating

3.7

Based on 50 reviews for this supplier

Rating Snapshot

The following is the distribution of all ratings

5 stars

4 stars

67%

3 stars

33%

2 stars

1 stars

All Reviews

Juan

Argentina Feb 18.2026

Helpful (2)

The finning is tight — you can tell they used a proper cold-forming process because the fins don't move at all when you try to wiggle them. We've had issues before with other suppliers where the fins would come loose after a few thermal cycles, but these ones feel solid.

Rashid

United Arab Emirates Dec 10.2025

Helpful (2)

Good oxidation resistance, matches well with the T9. No scaling or thinning noticed.

Ivan Volkov

Russian Federation Nov 11.2025

Helpful (3)

As an engineer in Siberia, I tested these fin tubes in extreme cold (-30°C). The ASTM A213 T11 steel performed well with no thermal cracks, and cooling efficiency met expectations (88%). That said, the Russian-language documentation had translation errors in technical terms, causing minor confusion during installation.
