ASTM A179 With Aluminum 1060 Carbon Steel Extruded Fin Tube , Heat Exchanger And Air Cooler Application

Brand Name:	Yuhong
Model Number:	Extruded Fin tube , Aluminum Extruded Fin tube
MOQ:	1 PC
Price:	Negotiable
Packaging Details:	Ply-Wooden Case + Iron Frame
Payment Terms:	TT, LC

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ABS, BV, DNV, CCS, LR

Base Tube Material Grade:

Base Tube Material Standard:

ASTM A179, ASME SA179

Type:

Straight Tube , U Bend Tube , Coil Tube

Application:

Air Cooler, Cooling Tower, Heat Exchanger, Condenser

Fin Type:

Extruded Fin Tube , Aluminum Extruded Fin Tube , Fin Tube

Fin Material:

Aluminum , Copper , Stainless Steel , Carbon Steel

Supply Ability:

10000 Tons/Month

Highlight:

ASTM A179 Fin Tube

Fin Tube Aluminum 1060

carbon steel tube air cooler

Product Description

ASTM A179 with Aluminum 1060 Carbon Steel Extruded Fin Tube , Heat Exchanger and air cooler application

Extruded Fin Tubes are a type of fin tubes which have extruded fins from the outer surface. The base tube is made to slide inside the outer tube made of copper or aluminum. And this assembly of the inner and outer tube is passed through an automatic extrusion machine. During the extrusion process, the fins are extruded from the outer tube to the desired height, thickness.

ASTM A179 Carbon Steel Extruded Fin Tube is a heat exchange element. In order to improve the heat exchange efficiency, fins are usually added to the surface of the ASTM A179 seamless tube to increase the outer surface area or inner surface area of the base tube, so as to achieve the purpose of improving the heat exchange efficiency.

Chemical Composition of ASTM A179 / ASME SA179 :

C	Mn	P	S
0.06-0.18	0.27-0.63	≤0.035	≤0.035

Mechanical Properties of ASTM A179 / ASME SA179 :

Tensile Strength, MPa	325 min
Yield Strength, MPa	180 min
Elongation, %	35 min
Hardness, HRB	72 max

Applications:

Condenser
Evaporator
Desalination
Fertilization
Petrochemical Industries
Paper and Pulp Plants
Building Industries
Food Industry
Heat Exchangers
Power Plants
Oil and Gas Plants

ASTM A179 With Aluminum 1060 Carbon Steel Extruded Fin Tube , Heat Exchanger And Air Cooler Application 0
