| Brand Name: | Yuhong |
| MOQ: | 1PC |
| Price: | Negotiable |
| Payment Terms: | TT, LC |
| Supply Ability: | 10000 tons/month |
1. A312 TP304H Base Tube Composition
| Grade | UNS Designation | C | Mn | P | S | Si | Cr | Ni | Mo | Other |
| TP304H | S30409 | 0.04-0.1 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-11.0 | ... | ... |
2. A312 TP304H Seerated Fin Tube Material Specification:
ASTM A312: This specification covers seamless and welded austenitic stainless steel pipes intended for high-temperature service.
TP304H: This is a specific grade of stainless steel, which is a higher carbon version of 304, offering improved strength at elevated temperatures.
3. A312 TP304H Seerated Fin Tube Key Features:
Serrated Fin Tubes: These tubes are designed with serrated or enhanced surface areas to improve heat transfer efficiency. The serration increases the surface area exposed to the fluid, promoting better heat exchange.
Corrosion Resistance: TP304H exhibits excellent resistance to corrosion, making it suitable for various applications, including heat exchangers and boilers.
High-Temperature Performance: The “H” designation indicates that this material has been optimized for high-temperature applications, maintaining strength and durability under extreme conditions.
4. A312 TP304H Seerated Fin Tube Applications:
5. A312 TP304H Seerated Fin Tube Benefits:
Improved thermal efficiency due to the serrated design.
Enhanced strength and durability at high temperatures.
Long service life in corrosive environments.
