ASTM A213 T22 High Frequency Welded Serrated Fin Tube For HVAC Systems

Brand Name:	YUHONG
MOQ:	200-500KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Cases with Steel Frames (both ends of pipes have plastic caps）
Payment Terms:	L/C,T/T,AT SIGHT

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ABS, BV, ISO, ASTM, SGS

Fin Type:

HFW Fin Tube, Serrated Fin Tube

Bare Tube Specification&Material:

ASTM A213 T22

Application:

Heat Exchangers, Condensers, And Reactors

Welding Area:

According To Actual Demand

Highlight:

High Frequency Welding Finned Tube, Condensers Serrated Finned Tube, Serrated Spiral Finned Tube

Supply Ability:

According to Clients' requirements

Highlight:

T22 Serrated Fin Tube

HVAC System Serrated Fin Tube

High Frequency Serrated Fin Tube

Product Description

1. What is ASTM A213 T22 Serrated Fin Tube?

ASTM A213 T22 Serrated Fin Tube is a high-efficiency heat transfer solution engineered for extreme ash-laden and high-temperature environments. It features a seamless chromium-molybdenum alloy steel base tube (ASTM A213 T22, UNS K21590) with helically wound serrated carbon steel fins bonded via high-frequency welding (HFW). The serrated fin edges disrupt boundary layers, enhancing heat transfer by 35% while reducing ash fouling by 50% compared to smooth fins. Ideal for boiler superheaters, reformers, and waste heat recovery systems operating up to 590°C (1,094°F).

2. Chemical & Mechanical Properties

Chemical Composition (%)

ASTM A213 T22 Chemical Composition(%)
Element	C	Si	Mo	P	Si	Cr	S
Range	0.05-0.15	≤ 0.50	0.87-1.13	≤ 0.025	≤0.50	1.90-2.60	≤0.025

Mechanical Properties (Post-Weld HT)

ASTM A213 T22 Mechanical Properties
Tensile Strength	Yield Strength	Elongation	Hardness	Max Service Temp.
≥415 MPa	≥205MPa	≥30%	≤ 163 HB	590°C (1094°F)

3. Key Applications & Competitive Advantages

● Coal-Fired Boilers: Superheaters in 550°C+ units (resists >60g/Nm³ fly ash).

● Waste Incinerators: Convection sections for municipal solid waste (MSW) plants.

● Refinery Heaters: Vacuum residue upgrading units (sulfidation resistance per NACE RP0472).

● Biomass Energy: High-alkali flue gas economizers.

● Cement Plants: Preheater exhaust gas recovery.

4.Why choose ASTM A213 T22 Studded Fin Tube:

A:Company Competitiveness:

Yuhong Holding Group has more than 35 years experience for steel pipe and tube , fin tube , main application for Petrochemical , Oil refinary, Furnace, heating, boiler, heat exchanger, air cooler,.., till now YUHONG brand products already exported more than 85 countries, which like UK, ITALY, SPAIN , USA, MEXICO , COLOMBIA , BRAZIL, SAUDI ARANBIA , OMAN, QATAR, U.A.E, KOREA, ...., YUHONG brand already won good reputation in the market.

B:Product Competitiveness:
●  Anti-Fouling Design: 50% lower ash buildup vs. smooth fins (EPRI AC-7891).
●  8-Year Lifespan: Withstands thermal cycling per ASME Sec. I.
●  Cost Saving: 40% lower cost vs. TP347H finned tubes.
●  Rapid Delivery: 80+ standard sizes (OD 25–152mm) in stock.
