ASTM A312 TP347 Serrated Spiral High Frequency Welding Finned Tube For Condensers

Brand Name:	YUHONG
MOQ:	200-500KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Cases with Steel Frames(both ends of pipes have plastic caps）
Payment Terms:	L/C,T/T,AT SIGHT

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ABS, BV, ISO, ASTM, SGS

Product Name:

HFW Serreted Finned Tube

Bare Tube Specification & Material:

ASTM A312 TP347

Fin Height:

10~50mm

Fin Thick:

0.3~3mm

Highlight:

ASTM A312 Finned Tube, Serrated Spiral Finned Tube, Heat Exchanger Finned Tube

Application:

Power Plants , Chemical Plants, Oil Refineries

Supply Ability:

According to Clients' requirements

Highlight:

High Frequency Welding finned tube

Condensers Serrated finned tube

Serrated Spiral finned tube

Product Description

ASTM A312 TP347 Serrated Spiral High Frequency Welding Finned Tube For Condensers

Product Specifications

Product Name: HFW Serreted Finned Tube

Bare Tube Specification & Material: ASTM A312 TP347

Fin Height: 10~50mm

Fin Thick: 0.3~3mm

Applications: Power Plants, Chemical Plants, Oil Refineries

Product Overview

ASTM A312 TP347 Serrated Spiral High-Frequency Welding (HFW) Finned Tube is an advanced heat transfer solution designed for extreme oxidation and creep resistance. This high-performance component combines a seamless stabilized austenitic stainless steel base tube (ASTM A312 TP347) with helically wound serrated spiral fins bonded via high-frequency resistance welding.

Key Advantages: Serrated fin edges disrupt boundary layers, enhancing heat transfer by 35% compared to smooth fins, while the Nb-stabilized alloy provides exceptional resistance to intergranular corrosion at temperatures up to 870°C (1,598°F). Ideal for high-ash flue gases and cyclic thermal shock applications.

Material Properties

Chemical Composition (Per ASTM A312/A999)

Element	TP347 Base (%)	Critical Function
Chromium (Cr)	17.0-20.0	Oxidation shield
Nickel (Ni)	9.0-13.0	Austenite stability
Niobium (Nb)	10×C min*	Intergranular corrosion resistance
Carbon (C)	≤ 0.08	Weldability
Manganese (Mn)	≤ 2.00	Strength
Silicon (Si)	≤ 1.00	Deoxidation
Phosphorus (P)	≤ 0.045	Purity
Sulfur (S)	≤ 0.030	Machinability

Mechanical Properties (Post-Weld Annealed)

Property	Value
Tensile Strength	≥ 515 MPa
Yield Strength	≥ 205 MPa
Max Service Temp.	870°C (1,598°F)
Hardness	≤ 192 HB
Fin Bond Shear Strength	> 140 MPa
Oxidation Resistance	≤ 0.1 g/m²*h (980°C/air)

Key Applications

Waste-to-Energy Boilers: Superheaters in municipal waste incinerators (resists KCl/ZnCl₂ corrosion)
Refinery Heaters: Convection sections for vacuum residue upgrading
Chemical Processing: Cracked gas heat exchangers in ethylene plants
Power Generation: SCR duct heaters for coal-fired units (handles fly ash erosion)
Cement Plants: Preheater exhaust gas economizers

Engineering Benefits

Zero Carbide Precipitation: Nb stabilization prevents sensitization in 425-870°C range
Ash Self-Cleaning: Serrated fins reduce fouling by 50% (per EPRI study)
Thermal Fatigue Resistance: 2x longer life than TP304H in cyclic duty
Customization Options: Fin height (12-25mm), serration depth (1-3mm), FPI (3-8)
