ASTM A333 Gr1 Seamless Carbon Alloy Low Fin Tubes For Air Coolers

Brand Name:	Yuhong
Model Number:	ASTM A333 Gr1
MOQ:	Depend the size of finned tubes, 50-100PC
Price:	Negotiable
Packaging Details:	Ply-wooden Case With Iron Frame
Payment Terms:	TT, LC

Detail Information

Product Description

Ratings & Reviews

Detail Information

Place of Origin:

China

Certification:

ABS, BV, DNV, CCS, LR

Product:

Fin Tubes Or Finned Tube

Type:

Low Fin Tubes / Integral Fin Tubes

Low Fin Tubes Standard:

ASTM A179

Low Fin Tubes Material:

Low Fin Tubes Use:

Air-Cooled Heat Exchangers,Evaporators And Condensers,Radiators,Process Heating/Cooling,etc.

Low Fin Tubes Packing:

Ply-wooden Case With Iron Frame

Supply Ability:

1000 tons/month

Highlight:

Seamless Carbon Alloy Low Fin Tubes

Air Coolers Low Fin Tubes

ASTM A333 Gr1 Low Fin Tubes

Product Description

ASTM A333 Gr1 Seamless Carbon Alloy Low Fin Tubes For Air Coolers

This specification A333 covers nominal (average) wall seamless and welded carbon and alloy steel pipe intended for use at low temperatures.ASTM A333 Gr.1 low fin tubes are specialized heat exchanger tubes designed for air coolers and other heat transfer applications. These tubes feature an externally finned surface to enhance heat transfer efficiency while maintaining the low-temperature toughness required for cryogenic and sub-zero environments.

Chemical Composition (%)

Grade	C	Mn	P	S
Gr.1	0.30	0.40-1.06	0.025	0.025

Mechanical Properties

Grade	Tensile Strength,min	Yield Strength (0.2%Offset,min)	Elongation min.
Gr.1	55ksi (380 MPa)	30ksi (205 MPa)	35%

Advantages

Enhanced Heat Transfer – Fins increase surface area for better air-side heat exchange.

Low-Temperature Toughness – Suitable for sub-zero applications, with excellent impact resistance at low temperatures.

Cost-Effective – More efficient than bare tubes, reducing equipment size.

ASTM A333 Gr1 Seamless Carbon Alloy Low Fin Tubes For Air Coolers 0

Application ( Not limited to the following )

Air-cooled heat exchangers (ACHEs)

Process cooling in refineries, petrochemical, and LNG plants

Low-temperature heat transfer (down to -45°C / -50°F)

ASTM A333 Gr1 Seamless Carbon Alloy Low Fin Tubes For Air Coolers 1
