High Frequency Welding Fin Tube Serrated Type ASTM A312 TP304H For Power Plant Furnace

Brand Name:	Yuhong
Model Number:	Serrated, Helical Serrated
MOQ:	1 PC
Price:	Negotiable
Packaging Details:	Ply-Wooden Case + Iron Frame
Payment Terms:	TT, LC

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ABS, BV, DNV, CCS, LR

Base Tube Material Grade:

TP304H

Base Tube Material Standard:

ASME SA312 , ASTM A312

Type:

Serrated , Helical Serrated

Application:

Furnace Tube, Tube Coil , Radiate Tube , Convenction Tube , Fired Heater

Fin Type:

Serrated Fins

Fin Material:

Carbon Steel , Stainless Steel , Alloy Steel

Supply Ability:

10000 Tons/Month

Highlight:

Power Plant Furnace Welding Fin Tube

Serrated Type Welding Fin Tube

ASTM A312 TP304H Welding Fin Tube

Product Description

High Frequency Welding Fin Tube, Serrated Type, ASTM A312 TP304H, Power Plant Furnace Application

ASTM A312 TP304H Serrated Fin Tube is a high-performance stainless steel tube used in heat transfer applications. The TP304H grade is an austenitic stainless steel with enhanced carbon content, providing improved high-temperature strength.

The increased carbon content in TP304H enhances its strength at elevated temperatures. The tube's ability to maintain strength and resist corrosion at elevated temperatures ensures long-lasting performance and improved system efficiency. It offers excellent resistance to oxidation and corrosion, making it suitable for high-temperature environments. It provides long-lasting performance in demanding applications.

Chemical Composition:

Grade	Cr	Ni	C	Mn	Si	P	S
TP304H	18.0-20.0%	8.0-11.0%	0.04-0.10%	2.0% max	1.0% max	0.045% max	0.030% max

Mechanical Properties:

Grade	Tensile Strength	Yield Strength	Elongation	Hardness
TP304H	≥ 205 MPa (30 ksi)	≥ 515 MPa (75 ksi)	≥ 35% in 50 mm	Typically ≤ 90 HRB

Applications:

1. Power Generation

Boilers and Superheaters: Enhance heat transfer efficiency in power plants. Withstand high steam temperatures, improving overall plant efficiency.

2. Petrochemical Industry

Refineries: Used in catalytic reforming and other high-temperature processes. Provides durability and resistance to corrosive chemicals.
Chemical Processing: Essential for heat exchangers handling aggressive and high-temperature fluids. Ensures long-term reliability in harsh chemical environments.

3. Oil and Gas Industry

Offshore Platforms: Suitable for heat exchangers exposed to harsh marine conditions. Resists corrosion and maintains strength under pressure.
Refinery Furnaces: Efficiently transfers heat in high-pressure operations. Enhances system performance and reduces downtime.

4. Industrial Boilers

Economizers: Recover heat from flue gases to preheat boiler feedwater. Improve boiler efficiency and reduce energy costs.
Steam Distribution Systems: Ensure reliable operation under varying thermal conditions. Maintain consistent steam quality and temperature.

High Frequency Welding Fin Tube Serrated Type ASTM A312 TP304H For Power Plant Furnace 0
